| Brand | Xeltek |
|---|---|
| Products Status | New |
| Model | XQR5VFX130-1CN1752B |
| Application | Embedded |
| Speed | 4.25 Gb/s |
| Product Category | FPGA – Field Programmable Gate Array |
| Distributed RAM | 1580 kbit |
| Mounting Style | SMD/SMT |
| Adaptive Logic Modules - ALMs | 20480 ALM |
| Embedded Block RAM - EBR | 10728 kbit |
| Minimum Operating Temperature | – 55 C |
| Maximum Operating Temperature | + 125 C |
| Embedded Memory | 10.48 Mbit |
| Number of Logic Elements | 131072 LE |
| Supply Voltage - Min | 1V |
| Number of I/Os | 836 I/O |
| Number of Transceivers | 18 Transceiver |
| Package/Case | FPGA-1752 |
* NOTE: Image may not exactly match the product
Xilinx XQR5VFX130-1CN1752B
The Xilinx XQR5VFX130-1CN1752B is a radiation-hardened FPGA designed for mission-critical aerospace and defense applications. This high-performance device features 130,000 logic cells, dual PowerPC processors, and advanced DSP capabilities, delivering exceptional processing power in extreme environments. Key benefits include immunity to single-event upsets, extended temperature range operation (-55°C to +125°C), and proven reliability in space missions. Its unique radiation tolerance, combined with reconfigurable logic and embedded processing, makes it ideal for satellite systems, military avionics, and deep-space exploration where failure is not an option. The device offers unmatched durability and performance consistency in the harshest operating conditions.
