WIO A+ Server AS -1114S-WN10RT (Complete System Only

* NOTE: Image may not exactly match the product

WIO A+ Server AS -1114S-WN10RT (Complete System Only

**WIO A Server AS-1114S-WN10RT Complete System**

High-performance 1U rackmount server delivering enterprise-grade reliability and scalability. Features dual Intel Xeon processor support, up to 1TB DDR4 ECC memory capacity, and hot-swappable drive bays for maximum uptime. Built-in redundant power supplies and advanced thermal management ensure 24/7 operation stability.

**Key Benefits:**
– **Space-efficient design** – 1U form factor maximizes datacenter density
– **Enterprise reliability** – ECC memory and redundant components minimize downtime
– **Scalable performance** – Dual processor architecture grows with business needs
– **Easy maintenance** – Hot-swappable components enable service without shutdown
– **Energy efficient** – Optimized power consumption reduces operational costs

**Ideal for:** Virtualization, database hosting, cloud computing, and mission-critical applications requiring robust performance in compact footprint. Complete turnkey solution eliminates integration complexity.

Quote1 Piece(MOQ)

Bulk Order Discounts Available

BrandSupermicro
Products StatusNew
ApplicationsAll Flash Storage, Cloud Computing, Virtualization
Max GPU1
CPU TypeAMD EPYC 7002/7003 Series Processors

Product SKUs

  • A+ ServerAS -1114S-WN10RTStandard version with PWS-706P-1R (Platinum Level)
  • A+ ServerAS -1114S-WN10RT-EUEuropean version with PWS-861A-1R (Titanium Level)

Motherboard

  • Super H12SSW-NTR

Processor

  • CPU
    Single Socket SP3
    AMD EPYC 7002/7003 Series Processors
  • Core Count
    Up to 64C/128T

System Memory

  • Memory
    Slot Count: 16 DIMM slots
    Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM

On-Board Devices

  • SATA
    SATA (6Gbps)
  • Chipset
    AMD System on Chip
  • Network Connectivity
    2 RJ45 10GBASE-T with Broadcom BCM57416
  • IPMI
    Support for Intelligent Platform Management Interface v.2.0
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
    2 RJ45 10 GBASE-T LAN ports
  • USB
    2 USB 3.0 ports(front)
    4 USB 3.0 ports(rear)
    1 USB 3.0 port(Rear)
  • Video
    1 VGA port
  • DOM
    2 Super DOM (Disk on Module) ports

System BIOS

  • BIOS Type
    AMI 256MB SPI Flash ROM

Management

  • Power configurations
    ACPI/APM Power Management

Chassis

  • Form Factor
    1U Rackmount
  • Model
    CSE-116TS-R706WBP5-N10

Dimensions and Weight

  • Height
    1.7″ (43 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    23.5″ (597 mm)
  • Package
    8″ (H) x 24″ (W) x 32″ (D)
  • Weight
    Gross Weight: 39 lbs (17.69 kg)
    Net Weight: 25 lbs (11.34 kg)
  • Available Color
    Black

Front Panel

  • LED
    Device Activity
    LAN 1 Activity
    LAN 2 Activity
    Power status
    System information
  • Buttons
    Power On/Off
    UID button

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 2 PCIe 4.0 x16 FHHL slots 1 PCIe 4.0 x16 LP slot
  • M.2
    2 M.2 PCIe 4.0 x2 NVMe slots (M-key 2280/22110)

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 10 bays 10 front hot-swap 2.5″ NVMe/SATA drive bays
  • M.2

System Cooling

  • Fans
    6 heavy duty fans with optimal fan speed control

Power Supply

  • 2x 750W
    2x 750W Redundant (1 + 1) Platinum Level (94%) power supplies
    Dimension (WxHxL)
    54.5 x 40.25 x 320 mm
    Total Output Power
    Input
    700W: 100-140Vac / 50-60Hz
    750W: 100-240Vac
    750W: 200-240Vac / 50-60Hz
    +12V
    Max: 58A / Min: 0.5A (100Vac-140Vac)
    Max: 62A / Min: 0.5A (200Vac-240Vac)
    Max: 62A / Min: 0.5A
    5V SB
    Max: 3A / Min: 0A
    Output Type
    Backplanes (gold finger)
    Certification
    Platinum Level
    [
    Test Report
    ]
Brand

Supermicro
Products Status

New
Applications

All Flash Storage, Cloud Computing, Virtualization
Max GPU

1
CPU Type

AMD EPYC 7002/7003 Series Processors
Total PCI-E Slots

3
Drives

10
Drive Form Factors

2.5"
Form Factor

1U
Generation

H12
Interface

NVMe (Native), SAS (Optional), SATA (Optional)
SATA

SATA (6Gbps)
LED

Device ActivityLAN 1 ActivityLAN 2 ActivityPower statusSystem information
Network Connectivity

1 RJ45 10GBASE-T with Broadcom BCM57416View AOC Options
LAN

1 RJ45 1 GbE Dedicated BMC LAN port2 RJ45 10 GBASE-T LAN ports
BIOS Type

AMI 256MB SPI Flash ROM
Package

8" (H) x 24" (W) x 32" (D)
Depth

23.5" (597 mm)
Fans

6 heavy duty fans with optimal fan speed control
Height

1.7" (43 mm)
Buttons

Power On/OffUID button
M.2

2 M.2 PCIe 4.0 x2 NVMe slots (M-key 2280/22110)
Memory

Slot Count: 16 DIMM slotsMax Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMMView Memory Options
Width

17.2" (437 mm)
Video

1 VGA port
ROHS

RoHS Compliant
Core Count

Up to 64C/128T
Note

Supports up to 280W TDP CPUs (Air Cooled)
Weight

Gross Weight: 39 lbs (17.69 kg)Net Weight: 25 lbs (11.34 kg)
Drive Bays Configuration

Default: Total 10 bays
USB

2 USB 3.0 ports(front)4 USB 3.0 ports(rear)1 USB 3.0 port(Rear)
Available Color

Black
PCI-Express (PCIe) Configuration

Default
IPMI

Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
CPU

Single Socket SP3AMD EPYC 7002/7003 Series Processors
Chipset

AMD System on Chip
DOM

DOM
