WD Ultrastar DC HC550 16TB Hard Drive 3.5" Internal 512MB SATA 7200 RPM 512E SE NP3 DC HC550 0F38462 (WUH721816ALE6L4)

Brand

Western Digital

Products Status

New

Application

Server

Interface

SATA 6Gb/s

Capacity

16TB

Ultrastar DC HC550 : High density storage

The Western Digital Ultrastar DC HC550 16TB hard drive is designed specifically for professionals in data centers. This 3.5″ hard drive offers numerous advantages for server use, including RVS anti-vibration technology, a workload rating of 550TB per year, and an MTBF (Mean Time Between Failures) of 2.5 million hours.

Part of the DC HC500 Series, this drive is available in capacities starting from 10TB. It is ideal for enterprise servers, backup systems, cloud environments, and enterprise NAS that require 4096-byte (4Kn) sector size for enhanced performance and high-density storage, leveraging HelioSeal technology.

DESIGNED FOR DATA CENTRES

The Ultrastar DC HC550 incorporates advanced multi-axis shock sensor technology, which automatically detects and compensates for minor shocks to safeguard the data stored on the drive. It also includes RAID-specific features, such as optimized error recovery processes that minimize downtime in RAID configurations.

Additionally, the drive utilizes ramp load/unload technology, which moves the recording heads away from the disk platters during idle periods and when powering down. This technology helps reduce wear and tear on the recording heads and media, enhancing overall drive reliability and longevity.

Brand	Western Digital
Products Status	New
Application	Server
Interface	SATA 6Gb/s
Capacity	16TB
Form Factor	3.5"
Cache	512MB
RPM	7200 RPM
Model	WUH721816ALE6L4
Series	Ultrastar DC HC550
Height (maximum)	26.10mm
Length (maximum)	147.00mm
Width (maximum)	101.60mm
