Supermicro SYS-821GE-TNHR

The Supermicro SYS-821GE-TNHR is a high-performance 2U rackmount server designed for demanding enterprise workloads. This dual-socket system supports 4th Gen Intel Xeon Scalable processors with up to 56 cores per CPU, delivering exceptional computational power for virtualization, databases, and HPC applications.

**Key Features:**
– Dual Intel Xeon Scalable processor support (4th Gen)
– 32 DIMM slots supporting up to 8TB DDR5 memory
– 8x 2.5″ hot-swappable drive bays with NVMe/SATA support
– Dual 10GbE networking with optional 25GbE/100GbE upgrades
– Redundant 1200W 80 PLUS Titanium power supplies
– Advanced thermal management with optimal airflow design

**Benefits:**
– Maximizes performance per rack unit with dense computing power
– Reduces operational costs through energy-efficient Titanium PSUs
– Ensures business continuity with hot-swappable components and redundancy
– Scales seamlessly from small deployments to large data centers
– Minimizes downtime with tool-less maintenance design

**Unique Selling Points:**
– Supermicro’s proven reliability and build quality for mission-critical environments
– Optimized for both general-purpose computing and specialized AI/ML workloads
– Comprehensive management suite with IPMI 2.0 and Redfish support
– Cost-effective alternative to major OEM solutions without compromising performance

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
Form Factor8U
Products StatusNew
MemorySlot Count: 32 DIMM slotsMax Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMMMax Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMMView Memory Options
Drive Form Factors2.5"

FEATURES / SPECIFICATIONS

SYS-821GE-TNHR Supermicro 8U 20 Bay 2xLGA 4677256GB(32DIMMS)4800MHz20x2.5??NVe/SATA(8xonly NVMe)2xM.2 10xPCIE 1
INTEL XEON PLATINUM 8468 CPU 2
64GB DDR5 4800MHZECCREGISTERED 32
960GB 2.5 NVME PCIE4 SSD 2
7.6TB 2.5 NVME PCIE4 SSD 2
MCX75310AAS-NEAT 400GB DR-900-9X766-003N-S00 8
GPU-NVHGX-H100-88 NVDIA Delta-next GPubaseboard,8xH100 80GB SX5 1
MCX623106AC-CDAT 100GbE thernet 1
AOM-TPM-9670V-0 SPI TPM 2.0 USING SLB9670 1
A0C-STGC-I2T-0 Standard low profile 2-port10G R45??Intel X550 1
Brand

Supermicro

Form Factor

8U

Products Status

New

Memory

Slot Count: 32 DIMM slotsMax Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMMMax Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMMView Memory Options

Drive Form Factors

2.5"

Chipset

Intel C741

CPU

Dual Socket E (LGA-4677)5th Gen Intel Xeon

CPU Type

5th Gen Intel Xeon/4th Gen Intel Xeon Scalable processors

Generation

X13

Total PCI-E Slots

12

Drives

15

Max GPU

Up to 8

Fans

10 heavy duty fans with optimal fan speed control

Depth

33.2" (843.28 mm)

Height

14" (355.6 mm)

Width

17.2" (437 mm)

Package

29.5" (H) x 27.5" (W) x 51.2" (D)

PCI-Express (PCIe) Configuration

Default

Weight

Gross Weight: 225 lbs (102.1 kg)Net Weight: 166 lbs (75.3 kg)

Drive Bays Configuration

Default: Total 15 baysOption A: Total 19 bays(*NVMe support may require additional storage controller and/or cables, please see the optional parts list for details)

Video

1 VGA port

Network Connectivity

2 RJ45 10GbE with Intel X550-AT2 (optional)2 SFP28 25GbE with Broadcom BCM57414 (optional)2 RJ45 10GbE with Intel X710-AT2 (optional)View AOC Options

BIOS Type

AMI 32MB SPI Flash EEPROM

Note

Supports up to 350W TDP CPUs (Air Cooled)

Available Color

Black front & silver body

Buttons

Power On/Off buttonSystem Reset button

M.2

2 M.2 NVMe slots (M-key)

LED

Hard drive activity LEDNetwork activity LEDsPower status LEDSystem Overheat & Power Fail LED

Application

AI/Deep Learning Training, Business Intelligence & Analytics, Climate and Weather Modeling, Conversational AI, Drug Discovery, Finance & Economics, Healthcare, High Performance Computing, Industrial Automation, Retail

Max GPU Count

Up to 8 onboard GPUs

Core Count

Up to 64C/128T; Up to 320MB Cache per CPU

Memory Voltage

1.1V

CPU-GPU Interconnect

PCIe 5.0 x16 CPU-to-GPU Interconnect

Supported GPUs

NVIDIA SXM: HGX H100 8-GPU (80GB), HGX H200 8-GPU (141GB)

GPU-GPU Interconnect

NVIDIA NVLink with NVSwitch
