Supermicro SYS-1029P-MT

The Supermicro SYS-1029P-MT is a high-performance 1U rackmount server designed for demanding enterprise workloads. This dual-socket system supports Intel Xeon Scalable processors, delivering exceptional computational power in a compact form factor. Key features include support for up to 3TB of DDR4 memory across 24 DIMM slots, dual 10GbE networking ports for high-speed connectivity, and flexible storage options with multiple drive bays supporting both SATA and NVMe configurations. The server offers redundant power supplies for enhanced reliability and features Supermicro’s advanced thermal design for optimal cooling efficiency. Its tool-less chassis design enables quick maintenance and upgrades, while comprehensive remote management capabilities through IPMI 2.0 ensure seamless administration. Ideal for virtualization, cloud computing, database applications, and high-frequency trading environments, the SYS-1029P-MT delivers enterprise-grade performance, scalability, and reliability in a space-efficient 1U package that maximizes data center density while minimizing operational costs.

Quote1 Piece(MOQ)

Premium Client Discounts Available

Product SKUs

SYS-1029P-MT
  • SuperServer 1029P-MT (Black)

Motherboard


Super X11DPL-i

Processor

CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,
    Dual UPI up to 10.4GT/s
  • Support CPU TDP 70-140W with IVR
Cores
  • Up to 28 Cores
Note  BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

System Memory

Memory Capacity
  • 8 DIMM slots
  • Up to 2TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
Memory Type
  • 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note  2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro

On-Board Devices

Chipset
  • Intel® C621 chipset
SATA
  • SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers
  • Marvell 88E1512 PHY Gigabit Ethernet controller
  • Supports 1000BASE-T
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video
  • ASPEED AST2500 BMC

Input / Output

SATA
  • 8 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 2.0 ports (rear)
Video
  • 1 VGA port
Serial Port / Header
  • 1 COM port (header)
DOM
  • 2 SuperDOM (Disk on Module) ports

System BIOS

BIOS Type
  • 256Mb SPI Flash EEPROM with AMI BIOS

Management

Software
  • Intel® Node Manager
  • IPMI 2.0
  • KVM with dedicated LAN
  • NMI
  • SSM, SPM, SUM
  • SuperDoctor® 5
  • Watch Dog
Power Configurations
  • ACPI / APM Power Management

PC Health Monitoring

CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
