Supermicro SSG-6039P-E1CR16L

The Supermicro SSG-6039P-E1CR16L is a high-performance 3U rackmount storage server designed for enterprise data centers requiring massive storage capacity and reliability. This powerhouse features dual Intel Xeon Scalable processor support, delivering exceptional computational performance for storage-intensive applications.

**Key Features:**
– Supports up to 16 hot-swappable 3.5″ drive bays for maximum storage flexibility
– Dual 10GbE networking ports for high-speed data transfer
– Up to 1TB DDR4 ECC memory capacity across 8 DIMM slots
– Redundant 920W 80 PLUS Platinum power supplies for mission-critical uptime
– Advanced IPMI 2.0 remote management capabilities

**Primary Benefits:**
– Massive scalable storage capacity ideal for big data, virtualization, and cloud applications
– Enterprise-grade reliability with hot-swappable components minimizing downtime
– Energy-efficient design reducing operational costs
– Tool-less chassis design for simplified maintenance and deployment

**Unique Selling Points:**
This server excels as a software-defined storage solution, perfect for organizations needing high-density storage with enterprise reliability. Its combination of powerful dual-processor architecture, extensive storage capacity, and robust remote management makes it ideal for data centers, backup solutions, and high-performance computing environments where storage performance and reliability are paramount.

Quote1 Piece(MOQ)

Premium Client Discounts Available

Product SKUs

SSG-6039P-E1CR16L
  • SuperStorage 6039P-E1CR16L (Black)

Motherboard


Super X11DPH-T

Processor/Cache

CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,
    3 UPI up to 10.4GT/s
  • Support CPU TDP 70-205W
Cores
  • Up to 28 Cores
Note  BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

System Memory

Memory Capacity
  • 16 DIMM slots
  • Up to 4TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM††
Memory Type
  • 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note  2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
†† Cascade Lake only. Contact your Supermicro sales rep for more info.

On-Board Devices

Chipset
  • Intel® C622 chipset
SAS
  • SAS3 (12Gbps) via Broadcom 3008 AOC
  • Broadcom 3008 controller
SATA
  • SATA3 (6Gbps) with RAID 0, 1, 5, 10
Network Controllers
  • Dual 10GBase-T LAN ports with Intel X722 + PHY Intel X557
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • ASPEED AST2500 BMC

Input / Output

LAN
  • 2 RJ45 10GBase-T LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 4 USB 3.0 ports (rear)
  • 1 Type A
VGA
  • 1 VGA port
Serial Port / Header
  • 1 Fast UART 16550 port / 1 Header

System BIOS

BIOS Type
  • 256Mb AMI UEFI

Management

Software
  • Intel® Node Manager
  • IPMI 2.0
  • NMI
  • SPM, SUM
  • SuperDoctor® 5
  • Watchdog

PC Health Monitoring

CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
