* NOTE: Image may not exactly match the product

Supermicro MBD-X13SEED-F

The Supermicro MBD-X13SEED-F is a high-performance server motherboard designed for enterprise and data center applications. Built on the Intel C741 chipset, it supports 4th Gen Intel Xeon Scalable processors with dual LGA4677 sockets, delivering exceptional computational power for demanding workloads.

**Key Features:**
– Dual LGA4677 sockets supporting Intel Xeon Scalable processors
– 32 DIMM slots supporting up to 8TB DDR5-4800 memory
– 8x PCIe 5.0 x16 slots and 2x PCIe 4.0 x8 slots for maximum expansion
– Dual 25GbE and dual 1GbE network ports for high-speed connectivity
– 16x SATA3 ports and M.2 slots for flexible storage options
– IPMI 2.0 with dedicated management port for remote administration

**Benefits:**
– Massive memory capacity enables handling of large datasets and memory-intensive applications
– Multiple high-speed PCIe slots accommodate GPUs, accelerators, and high-performance storage
– Redundant network interfaces ensure reliable connectivity and failover capabilities
– Comprehensive remote management reduces operational overhead

**Unique Selling Points:**
– Optimized for AI/ML workloads, HPC, and virtualization environments
– Supermicro’s proven reliability and enterprise-grade build quality
– Future-ready architecture supporting latest DDR5 and PCIe 5.0 standards
– Excellent price-to-performance ratio for dual-socket server deployments

Quote1 Piece(MOQ)

Bulk Order Discounts Available

BrandSupermicro
BIOS FeaturesACPI 6.4SMBIOS 2.8/3.5UEFI 2.8APlug and Play (PnP)PCI FW 3.2
TPM1 TPM Header & Chip both
Network ControllersSingle LAN with Intel i210 Gigabit Ethernet Controller
M.2M.2 Interface: 2 PCIe 5.0 x4Form Factor: 2280/22110Key: M-Key

Product SKUs

  • MBD-X13SEED-F

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    16.36″ x 8.53″ (41.56cm x 21.66cm)

Processor

  • CPU
    5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable processors
    Single Socket Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP
  • Core
    Up to 64 cores

System Memory

  • Memory Capacity
    8 DIMM slots
    Up to 2TB 3DS ECC RDIMM, DDR5-5600MT/s
  • Memory Type
    5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 5600MT/s(1DPC)
  • DIMM Sizes
    16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB
  • Memory Voltage
    1.1V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C741
  • IPMI
    ASPEED AST2600 BMC
  • Network Controllers
    Single LAN with Intel i210 Gigabit Ethernet Controller

Input / Output

  • USB
    2 USB 2 port(s) (2 type A Via KVM connector)
  • Video Output
    1 VGA port(s) Via KVM connector
  • Serial Port
    1 COM Port(s) (1 Serial Port Via KVM connector)
  • TPM
    1 TPM Header & Chip both

Expansion Slots

  • PCIe
    1 PCIe 5.0 x16 Right Riser Slot, support LP PCIe card,
    2 PCIe 5.0 x16 Left Riser Slot, support FHHL PCIe card
  • M.2
    M.2 Interface: 2 PCIe 5.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    32MB AMI UEFI
  • BIOS Features
    ACPI 6.4
    SMBIOS 2.8/3.5
    UEFI 2.8A
    Plug and Play (PnP)
    PCI FW 3.2

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v2.0 with KVM support
  • Power Configurations
    ACPI Power Management, Power-on mode control for AC power loss recovery
Brand

Supermicro

BIOS Features

ACPI 6.4SMBIOS 2.8/3.5UEFI 2.8APlug and Play (PnP)PCI FW 3.2

TPM

1 TPM Header & Chip both

Network Controllers

Single LAN with Intel i210 Gigabit Ethernet Controller

M.2

M.2 Interface: 2 PCIe 5.0 x4Form Factor: 2280/22110Key: M-Key

Chipset

Intel C741

DIMM Sizes

128GB, 16GB, 24GB, 256GB, 32GB, 48GB, 64GB, 96GB

BIOS Type

32MB AMI UEFI

Video Output

1 VGA port(s) Via KVM connector

Dimension

16.36" x 8.53" (41.56cm x 21.66cm)

PCIe

1 PCIe 5.0 x16 Right Riser Slot, 2 PCIe 5.0 x16 Left Riser Slot, support FHHL PCIe card, support LP PCIe card

USB

2 USB 2 port(s) (2 type A Via KVM connector)

Form Factor

Proprietary

Memory Type

5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 5600MT/s(1DPC)

Application

Server

IPMI

ASPEED AST2600 BMC

Memory Voltage

1.1V

CPU

5th Gen Intel XeonSingle Socket Socket E (LGA-4677) supported, CPU TDP supports Up to 350W TDP

Hardware

Trusted Platform Module (TPM) 2.0

Serial Port

1 COM Port(s) (1 Serial Port Via KVM connector)

Memory Capacity

8 DIMM slotsUp to 2TB 3DS ECC RDIMM, DDR5-5600MT/s

Error Detection

Corrects single-bit errors

Core

Up to 64 cores
