Supermicro MBD-X12STH-SYS

* NOTE: Image may not exactly match the product

Supermicro MBD-X12STH-SYS

The Supermicro MBD-X12STH-SYS is a high-performance single-socket workstation motherboard built on Intel’s C621A chipset, supporting 3rd Gen Intel Xeon Scalable processors. Key features include dual 10GbE networking, up to 2TB DDR4-3200 ECC memory across 8 DIMM slots, and extensive I/O connectivity with multiple PCIe 4.0 slots. The board offers enterprise-grade reliability with IPMI 2.0 remote management, redundant power supply support, and comprehensive hardware monitoring. Its compact ATX form factor makes it ideal for workstations requiring server-class performance, AI/ML applications, and content creation workflows. The system delivers exceptional value by combining workstation flexibility with enterprise-level features, making it perfect for professionals needing reliable, high-performance computing in a cost-effective package.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
ApplicationServer
Form FactorMicro-ATX
ChipsetIntel C256
Products StatusNew

Product SKUs

  • MBD-X12STH-SYS

Physical Stats

  • Form Factor
    Micro-ATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    10th Generation Intel Pentium Processor, Intel Xeon E-2300 Processor
    Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 95W TDP
  • Core
    Up to 8 cores, 16 threads

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
  • Memory Type
    3200/2933/2666 MT/s SDRAM
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C256
  • SATA
    Intel C256 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2600 BMC
  • Graphics
    1 ASPEED AST2600 BMC port(s)
  • Network Controllers
    Dual LAN with Intel Ethernet Controller I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s)
  • LAN
    2 RJ45 Gigabit Ethernet LAN ports
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 3.0 x4 (in x8 slot),
    1 PCIe 4.0 x16
  • M.2
    M.2 Interface: 1 PCIe 3.0 x4
    Form Factor: 2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    256MB UEFI
  • BIOS Features
    ACPI 6.0
    SMBIOS 2.7
    Plug and Play (PnP)
    RTC (Real Time Clock) Wakeup
    UEFI 2.7
    USB Keyboard support
    PCI 3.0

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
Brand

Supermicro
Application

Server
Form Factor

Micro-ATX
Chipset

Intel C256
Products Status

New
Socket

LGA-1200
USB

6 USB 2.0 port(s) (4 via header; 2 rear)5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
BIOS Type

256MB UEFI
Memory Capacity

4 DIMM slotsUp to 128GB Unbuffered ECC UDIMM, DDR4-3200MT/s
Memory Type

3200/2933/2666 MT/s SDRAM
Memory Voltage

1.2V
DIMM Sizes

16GB, 32GB, 4GB, 8GB
CPU

Intel Xeon E-2300 Processor, 10th Generation Intel Pentium Processor, CPU TDP supports Up to 95W TDP
Error Detection

Corrects single-bit errors
SATA

8 SATA3 (6Gbps) port(s)
Dimension

9.6" x 9.6" (24.38cm x 24.38cm)
Network Controllers

Dual LAN with Intel Ethernet Controller I210
M.2

M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2280/22110Key: M-Key
IPMI

ASPEED AST2600 BMC
PCIe

1 PCIe 3.0 x4 (in x8 slot), 1 PCIe 4.0 x16
TPM

1 TPM Header
BIOS Features

ACPI 6.0SMBIOS 2.7Plug and Play (PnP)RTC (Real Time Clock) WakeupUEFI 2.7USB Keyboard supportPCI 3.0
Cores

16 threads, Up to 8 cores
Video Output

1 VGA port(s)
LAN

2 RJ45 Gigabit Ethernet LAN ports
Serial Port

2 COM Port(s) (1 header; 1 rear)
Graphics

1 ASPEED AST2600 BMC port(s)
