Supermicro MBD-X11SPW-TF

* NOTE: Image may not exactly match the product

Supermicro MBD-X11SPW-TF

The Supermicro MBD-X11SPW-TF is a high-performance mini-ITX server motherboard designed for compact, power-efficient computing solutions. Built on the Intel C236 chipset with LGA1151 socket, it supports Intel Xeon E3-1200 v5/v6 and Core i3 processors. Key features include dual 10GbE SFP+ ports for ultra-fast networking, four DDR4 DIMM slots supporting up to 64GB ECC memory, and comprehensive I/O including USB 3.0, SATA 6Gb/s, and M.2 slots. The board offers enterprise-grade reliability with IPMI 2.0 remote management, hardware monitoring, and industrial-grade components. Its mini-ITX form factor makes it ideal for edge computing, network appliances, and space-constrained server deployments where high performance and advanced networking capabilities are essential. The integrated dual 10GbE connectivity eliminates the need for additional network cards, reducing costs and complexity while delivering exceptional throughput for demanding applications.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
ApplicationServer
Form FactorProprietary WIO
ChipsetIntel C622
Products StatusNew

Product SKUs

  • MBD-X11SPW-TF

Physical Stats

  • Form Factor
    Proprietary WIO
  • Dimension
    8″ x 13″ (20.32cm x 33.02cm)

Processor

  • CPU
    2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
    Single Socket Socket P (LGA-3647) supported, CPU TDP supports Up to 205W TDP
  • Core
    Up to 28 cores

System Memory

  • Memory Capacity
    6 DIMM slots
    Up to 1.5TB 3DS ECC LRDIMM, DDR4-2933MT/s; Up to 1.5TB 3DS ECC RDIMM, DDR4-2933MT/s
  • Memory Type
    2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
  • DIMM Sizes
    LRDIMM: 32GB, 64GB, 128GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C622
  • SATA
    Intel C622 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 10GBase-T with Intel X722 + X557

Input / Output

  • SATA
    10 SATA3 (6Gbps) port(s)
  • LAN
    2 RJ45 10GBase-T ports
  • USB
    7 USB 2.0 port(s) (2 rear; 5 via header)
    2 USB 3.0 port(s) (2 rear)
    3 USB 3 port(s) (2 via header; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    1 PCIe 3.0 x8 (in x16 slot),
    1 PCIe 3.0 x32 Left Riser Slot
  • M.2
    M.2 Interface: PCIe 3.0 x4; SATA
    Form Factor: 2280, 22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.0
    RTC (Real Time Clock) Wakeup
    SMBIOS 3.0 or later

Management

  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
Brand

Supermicro
Application

Server
Form Factor

Proprietary WIO
Chipset

Intel C622
Products Status

New
Socket

LGA-3647
USB

7 USB 2.0 port(s) (2 rear; 5 via header)2 USB 3.0 port(s) (2 rear)3 USB 3 port(s) (2 via header; 1 type A)
BIOS Type

AMI UEFI
Memory Capacity

6 DIMM slotsUp to 1.5TB 3DS ECC LRDIMM, DDR4-2933MT/s, DDR4-2933MT/s; Up to 1.5TB 3DS ECC RDIMM
Memory Type

2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
Memory Voltage

1.2V
DIMM Sizes

128GBRDIMM: 8GB, 16GB, 32GB, 64GB, LRDIMM: 32GB
CPU

2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
Error Detection

Corrects single-bit errors
SATA

10 SATA3 (6Gbps) port(s)
Dimension

8" x 13" (20.32cm x 33.02cm)
Network Controllers

Dual LAN with 10GBase-T with Intel X722 + X557
M.2

22110Key: M-Key, M.2 Interface: PCIe 3.0 x4; SATAForm Factor: 2280
IPMI

ASPEED AST2500
PCIe

1 PCIe 3.0 x32 Left Riser Slot, 1 PCIe 3.0 x8 (in x16 slot)
TPM

1 TPM Header
BIOS Features

ACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Cores

Up to 28 cores
Video Output

1 VGA port(s)
LAN

2 RJ45 10GBase-T ports
Serial Port

2 COM Port(s) (1 header; 1 rear)
Graphics

1 ASPEED AST2500 BMC port(s)
