Supermicro MBD-X11SPM-TPF

* NOTE: Image may not exactly match the product

Supermicro MBD-X11SPM-TPF

The Supermicro MBD-X11SPM-TPF is a high-performance micro-ATX server motherboard designed for Intel Xeon E3-1200 v5/v6 processors and 8th/9th generation Core processors. Key features include dual 10GbE LAN ports for exceptional network connectivity, TPM 2.0 security module for hardware-level encryption, and support for up to 64GB of DDR4 ECC/non-ECC memory. The board offers versatile expansion with PCIe 3.0 slots, multiple SATA 3.0 ports, and comprehensive I/O options including USB 3.0 and serial ports. Its compact micro-ATX form factor makes it ideal for space-constrained environments while delivering enterprise-grade reliability, advanced security features, and superior network performance for small business servers, workstations, and edge computing applications.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
BIOS FeaturesACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics1 ASPEED AST2500 BMC port(s)
TPM1 TPM Header
Network ControllersDual LAN with 10G SFP+ with Intel X722 + Inphi CS4227

Product SKUs

  • MBD-X11SPM-TPF

Physical Stats

  • Form Factor
    microATX
  • Dimension
    9.6″ x 9.6″ (24.38cm x 24.38cm)

Processor

  • CPU
    2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
    Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP
  • Core
    Up to 28 cores

System Memory

  • Memory Capacity
    6 DIMM slots
    Up to 1.5TB 3DS ECC LRDIMM, DDR4-2933MT/s; Up to 1.5TB 3DS ECC RDIMM, DDR4-2933MT/s
  • Memory Type
    2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
  • DIMM Sizes
    LRDIMM: 32GB, 64GB, 128GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C622
  • SATA
    Intel C622 controller for 12 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 10G SFP+ with Intel X722 + Inphi CS4227

Input / Output

  • SATA
    12 SATA3 (6Gbps) port(s)
  • LAN
    2 10G SFP+ LAN ports
  • USB
    6 USB 2.0 port(s) (4 via header; 2 rear)
    2 USB 3.0 port(s) (2 rear)
    3 USB 3 port(s) (2 via header; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    2 PCIe 3.0 x16,
    1 PCIe 3.0 x8
  • M.2
    M.2 Interface: PCIe 3.0 x4
    Form Factor: 2280, 2242
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.0
    RTC (Real Time Clock) Wakeup
    SMBIOS 3.0 or later

Management

  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
Brand

Supermicro
BIOS Features

ACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics

1 ASPEED AST2500 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with 10G SFP+ with Intel X722 + Inphi CS4227
M.2

2242Key: M-Key, M.2 Interface: PCIe 3.0 x4Form Factor: 2280
Chipset

Intel C622
DIMM Sizes

128GBRDIMM: 8GB, 16GB, 32GB, 64GB, LRDIMM: 32GB
BIOS Type

AMI UEFI
LAN

2 10G SFP+ LAN ports
Video Output

1 VGA port(s)
DOM

DOM
Dimension

9.6" x 9.6" (24.38cm x 24.38cm)
PCIe

1 PCIe 3.0 x8, 2 PCIe 3.0 x16
USB

6 USB 2.0 port(s) (4 via header; 2 rear)2 USB 3.0 port(s) (2 rear)3 USB 3 port(s) (2 via header; 1 type A)
Form Factor

Micro-ATX
Memory Type

2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
Application

Server
IPMI

ASPEED AST2500
Memory Voltage

1.2V
CPU

2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable ProcessorsSingle Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP
Serial Port

2 COM Port(s) (1 header; 1 rear)
SATA

12 SATA3 (6Gbps) port(s)
Memory Capacity

6 DIMM slotsUp to 1.5TB 3DS ECC LRDIMM, DDR4-2933MT/s, DDR4-2933MT/s; Up to 1.5TB 3DS ECC RDIMM
Error Detection

Corrects single-bit errors
Core

Up to 28 cores
