Supermicro MBD-X11SPL-F

* NOTE: Image may not exactly match the product

Supermicro MBD-X11SPL-F

The Supermicro MBD-X11SPL-F is a high-performance ATX server motherboard designed for enterprise workstations and entry-level servers. Built around the Intel C236 chipset, it supports 8th/9th generation Intel Xeon E and Core processors with LGA1151 socket compatibility. Key features include support for up to 128GB of DDR4-2666 ECC/non-ECC memory across four DIMM slots, dual Intel Gigabit Ethernet ports for redundancy and load balancing, and comprehensive I/O connectivity with multiple PCIe 3.0 slots for expansion cards. The board offers robust storage options with six SATA3 ports and M.2 connector support for NVMe SSDs. Its IPMI 2.0 with dedicated management LAN enables remote server management and monitoring. The motherboard delivers exceptional reliability through ECC memory support, enterprise-grade components, and Supermicro’s proven server-class design, making it ideal for small businesses, workstations, and cost-effective server deployments requiring professional-grade performance and manageability.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
BIOS FeaturesACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics1 ASPEED AST2500 BMC port(s)
TPM1 TPM Header
Network ControllersDual LAN with 1GbE with Intel I210

Product SKUs

  • MBD-X11SPL-F

Physical Stats

  • Form Factor
    ATX
  • Dimension
    12″ x 9.6″ (30.48cm x 24.38cm)

Processor

  • CPU
    2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
    Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP
  • Core
    Up to 28 cores

System Memory

  • Memory Capacity
    8 DIMM slots
    Up to 2TB 3DS ECC LRDIMM, DDR4-2933MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-2933MT/s
    Up to 1TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake Only)
  • Memory Type
    2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
  • DIMM Sizes
    LRDIMM: 32GB, 64GB, 128GB
    RDIMM: 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C621
  • SATA
    Intel C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with 1GbE with Intel I210

Input / Output

  • SATA
    8 SATA3 (6Gbps) port(s)
  • LAN
    2 RJ45 Gigabit Ethernet LAN ports
  • USB
    8 USB 2.0 port(s) (2 rear; 6 via header)
    2 USB 3.0 port(s) (2 rear)
    3 USB 3 port(s) (2 via header; 1 type A)
  • Video Output
    1 VGA port(s)
  • Serial Port
    2 COM Port(s) (1 header; 1 rear)
  • DOM
    2 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header

Expansion Slots

  • PCIe
    2 PCIe 3.0 x8 (in x16 slot),
    4 PCIe 3.0 x8,
    1 PCIe 3.0 x4 (in x8 slot)
  • M.2
    M.2 Interface: PCIe 3.0 x4; SATA
    Form Factor: 2280, 22110
    Key: M-Key

System BIOS

  • BIOS Type
    AMI UEFI
  • BIOS Features
    ACPI 6.0
    RTC (Real Time Clock) Wakeup
    SMBIOS 3.0 or later

Management

  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management
Brand

Supermicro
BIOS Features

ACPI 6.0RTC (Real Time Clock) WakeupSMBIOS 3.0 or later
Graphics

1 ASPEED AST2500 BMC port(s)
TPM

1 TPM Header
Network Controllers

Dual LAN with 1GbE with Intel I210
M.2

22110Key: M-Key, M.2 Interface: PCIe 3.0 x4; SATAForm Factor: 2280
Chipset

Intel C621
DIMM Sizes

128GBRDIMM: 8GB, 16GB, 32GB, 64GB, LRDIMM: 32GB
BIOS Type

AMI UEFI
LAN

2 RJ45 Gigabit Ethernet LAN ports
Video Output

1 VGA port(s)
DOM

DOM
Dimension

12" x 9.6" (30.48cm x 24.38cm)
PCIe

1 PCIe 3.0 x4 (in x8 slot), 2 PCIe 3.0 x8 (in x16 slot), 4 PCIe 3.0 x8
USB

8 USB 2.0 port(s) (2 rear; 6 via header)2 USB 3.0 port(s) (2 rear)3 USB 3 port(s) (2 via header; 1 type A)
Form Factor

ATX
Memory Type

2933/2666/2400/2133 MT/s ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
Application

Server
IPMI

ASPEED AST2500
Memory Voltage

1.2V
CPU

2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable ProcessorsSingle Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP
Serial Port

2 COM Port(s) (1 header; 1 rear)
SATA

8 SATA3 (6Gbps) port(s)
Memory Capacity

8 DIMM slotsUp to 2TB 3DS ECC LRDIMM, DDR4-2933MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-2933MT/sUp to 1TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake Only)
Error Detection

Corrects single-bit errors
Core

Up to 28 cores
