Supermicro MBD-X11SCE-F

The Supermicro MBD-X11SCE-F is a compact mini-ITX server motherboard designed for edge computing and space-constrained applications. Built on Intel’s C246 chipset, it supports 8th/9th generation Intel Core processors and up to 64GB of ECC/non-ECC DDR4 memory. Key features include dual Gigabit Ethernet ports, IPMI 2.0 with dedicated management LAN, PCIe 3.0 expansion slots, and multiple USB 3.0 ports. The board offers enterprise-grade reliability with ECC memory support, remote management capabilities, and industrial-grade components rated for 24/7 operation. Its mini-ITX form factor makes it ideal for edge servers, network appliances, and compact workstations where space is premium but performance and reliability cannot be compromised. The integrated IPMI provides out-of-band management for remote monitoring and control, making it perfect for distributed deployments and unmanned installations.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandSupermicro
ApplicationServer
Form FactorProprietary
ChipsetIntel C246
Products StatusNew

Product SKUs

  • MBD-X11SCE-F

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    4.6″ x 11.7″ (11.68cm x 29.72cm)

Processor

  • CPU
    Intel Celeron, Intel Pentium, Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor, 8th Generation Intel Core i3 Processor
    Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 80W TDP

System Memory

  • Memory Capacity
    4 DIMM slots
    128GB Unbuffered ECC UDIMM, DDR4-2666MT/s
  • Memory Type
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C246
  • SATA
    Intel C246 controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • IPMI
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
    HDD Fail detection via IPMI
  • Graphics
    1 ASPEED AST2500 BMC port(s)
    Via KVM Connector
  • Network Controllers
    Single LAN with Realtek RTL8211E PHY (dedicated IPMI), via Backplane

Input / Output

  • LAN
    1 RJ45 Dedicated IPMI LAN port
  • USB
    2 USB 2.0 port(s) (2 rear)
    USB 2.0 via KVM Connector
  • Video Output
    1 VGA port(s)
  • Serial Port
    1 fast UART 16550 Serial
    1 COM Port(s) (1 rear), Via KVM Connector
  • DOM
    1 Super DOM (Disk on Module) port with build power
  • TPM
    1 TPM Header
  • Others
    1 KVM Connector for VGA
    1 USB 0 and COM Ports

Expansion Slots

  • PCIe
    1 PCIe 3.0 x8 (Micro Low Profile)
  • M.2
    M.2 Interface: 11 SATA/PCIe 3.0 x4
    Form Factor: 2242/2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    256MB UEFI
  • BIOS Features
    ACPI 6.1
    SMBIOS 2.8
    SMBIOS 3.1
    UEFI 2.7
    USB Keyboard support
    Plug and Play (PnP)

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support, SUM
  • Power Configurations
    Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss
Brand

Supermicro
Application

Server
Form Factor

Proprietary
Chipset

Intel C246
Products Status

New
Socket

LGA-1151
USB

2 USB 2.0 port(s) (2 rear)USB 2.0 via KVM Connector
BIOS Type

256MB UEFI
Memory Capacity

4 DIMM slots128GB Unbuffered ECC UDIMM, DDR4-2666MT/s
Memory Type

2666/2400/2133MHz ECC DDR4 SDRAM
Memory Voltage

1.2V
DIMM Sizes

16GB, 32GB, 4GB, 8GB
CPU

8th Generation Intel Core i3 ProcessorSingle Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 80W TDP, Intel Celeron, Intel Pentium, Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor
Error Detection

Corrects single-bit errorsDetects double-bit errors (using ECC memory)
SATA

1, 10, 5, Intel C246 controller for 4 SATA3 (6 Gbps) ports; RAID 0
Dimension

4.6" x 11.7" (11.68cm x 29.72cm)
Network Controllers

Single LAN with Realtek RTL8211E PHY (dedicated IPMI), via Backplane
M.2

M.2 Interface: 11 SATA/PCIe 3.0 x4Form Factor: 2242/2280/22110Key: M-Key
IPMI

IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportHDD Fail detection via IPMI
PCIe

1 PCIe 3.0 x8 (Micro Low Profile)
TPM

1 TPM Header
BIOS Features

ACPI 6.1SMBIOS 2.8SMBIOS 3.1UEFI 2.7USB Keyboard supportPlug and Play (PnP)
Video Output

1 VGA port(s)
LAN

1 RJ45 Dedicated IPMI LAN port
Serial Port

1 fast UART 16550 Serial1 COM Port(s) (1 rear), Via KVM Connector
Graphics

1 ASPEED AST2500 BMC port(s)Via KVM Connector
