Supermicro MBD-X11OPi-CPU wholesale

* NOTE: Image may not exactly match the product

Supermicro MBD-X11OPi-CPU

The Supermicro MBD-X11OPi-CPU is a high-performance server motherboard featuring an integrated Intel Xeon D processor, delivering exceptional compute density in a compact form factor. Key features include support for up to 128GB DDR4 ECC memory, dual 10GbE networking ports, multiple PCIe expansion slots, and comprehensive I/O connectivity including USB 3.0 and SATA ports. This board excels in edge computing, virtualization, and storage applications where space efficiency and power optimization are critical. Its unique selling points include the pre-installed Xeon D CPU eliminating compatibility concerns, IPMI 2.0 remote management capabilities, and Supermicro’s proven enterprise-grade reliability. The integrated design reduces total cost of ownership while delivering server-class performance ideal for micro-datacenters, network appliances, and space-constrained deployments requiring robust processing power.

Quote1 Piece(MOQ)

Premium Client Discounts Available

BrandSupermicro
Graphics1 ASPEED AST2500 BMC port(s)(on PCH board)
Network Controllers(on PCH board), Quad LAN with Intel X550 10GBase-T Ethernet Controller
M.2M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1Form Factor: 2260/2280/22110
ChipsetIntel C621

Product SKUs

  • MBD-X11OPi-CPU

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    11″ x 14.33″ (27.94cm x 36.4cm)

Processor

  • CPU
    2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
    8 Socket Socket P (LGA-3647) supported, CPU TDP supports Up to 205W TDP, 3 UPI up to 10.4 GT/s
  • Core
    Up to 28 cores

System Memory

  • Memory Capacity
    12 DIMM slots
    Up to 3TB Intel Optane Persistent Memory 100 Series, DDR4-2666MT/s
    Up to 3TB 3DS ECC RDIMM, DDR4-2933MT/s
    Maximum System Capacity (8 CPU modules, 96 DIMM slots):Up to 24TB ECC DDR4 @ 2933 MHz RDIMM/LRDIMM,Up to 24TB Intel Optane DC Persistent Memory, Up to 36TB combined memory (DDR4and Optane DCPMM).
  • Memory Type
    2933/2666/2400/2133 MT/s ECC DDR4 RDIMM (3DS)
  • DIMM Sizes
    RDIMM: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C621
  • SATA
    Intel C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
    (on Storage board)
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
    (on PCH board)
  • Network Controllers
    Quad LAN with Intel X550 10GBase-T Ethernet Controller, (on PCH board)

Input / Output

  • USB
    2 USB 2.0 port(s) (2 via header)
    1 USB 3.2 Gen1 port(s) (1 type A)
    (on PCH board)
  • Video Output
    1 VGA D-Sub Connector port(s)
  • Others
    1 (TPM header on PCH board)

Expansion Slots

  • PCIe
    2 PCIe 3.0 x16
  • M.2
    M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1
    Form Factor: 2260/2280/22110
    (M.2 slots on PCH board)

System BIOS

  • BIOS Type
    AMI UEFI
Brand

Supermicro
Graphics

1 ASPEED AST2500 BMC port(s)(on PCH board)
Network Controllers

(on PCH board), Quad LAN with Intel X550 10GBase-T Ethernet Controller
M.2

M.2 Interface: 2 SATA/PCIe 3.0 x4, RAID 0 & 1Form Factor: 2260/2280/22110
Chipset

Intel C621
DIMM Sizes

128GB, 16GB, 256GB, 32GB, 64GB, RDIMM: 8GB
BIOS Type

AMI UEFI
Video Output

1 VGA D-Sub Connector port(s)
Dimension

11" x 14.33" (27.94cm x 36.4cm)
PCIe

2 PCIe 3.0 x16
USB

2 USB 2.0 port(s) (2 via header)1 USB 3.2 Gen1 port(s) (1 type A)(on PCH board)
Form Factor

Proprietary
Memory Type

2933/2666/2400/2133 MT/s ECC DDR4 RDIMM (3DS)
Application

Server
IPMI

ASPEED AST2500
Others

1 (TPM header on PCH board)
Memory Voltage

1.2V
CPU

2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors8 Socket Socket P (LGA-3647) supported, 3 UPI up to 10.4 GT/s, CPU TDP supports Up to 205W TDP
SATA

1, 10(on Storage board), 5, Intel C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0
Memory Capacity

12 DIMM slotsUp to 3TB Intel Optane Persistent Memory 100 Series, 96 DIMM slots):Up to 24TB ECC DDR4 @ 2933 MHz RDIMM/LRDIMM, DDR4-2666MT/sUp to 3TB 3DS ECC RDIMM, DDR4-2933MT/sMaximum System Capacity (8 CPU modules, Up to 24TB Intel Optane DC Persistent Memory, Up to 36TB combined memory (DDR4and Optane DCPMM).
Error Detection

Corrects single-bit errorsDetects double-bit errors (using ECC memory)
Core

Up to 28 cores
