* NOTE: Image may not exactly match the product

Supermicro MBD-X10QBL-CT

The Supermicro MBD-X10QBL-CT is a high-performance server motherboard featuring dual Intel Xeon E5-2600 v3/v4 processor support with up to 36 cores total. Key highlights include 16 DDR4 DIMM slots supporting up to 1TB of registered ECC memory, dual 10GbE LAN ports for high-speed networking, and comprehensive I/O expansion with multiple PCIe 3.0 slots. The board offers enterprise-grade reliability with IPMI 2.0 remote management, redundant power supply support, and advanced thermal monitoring. Its compact design maximizes density while delivering exceptional processing power, making it ideal for virtualization, cloud computing, database applications, and high-performance computing workloads where scalability, reliability, and energy efficiency are critical.

Quote1 Piece(MOQ)

Premium Client Discounts Available

BrandSupermicro
BIOS FeaturesPlug and Play (PnP)APM 1.2PCI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportSMBIOS 2.7.1UEFI 2.3.1
GraphicsAspeed AST2400 BMC
Serial Port / Header1 header), 2 COM Ports (1 rear
TPM1 TPM Header

Product SKUs

  • MBD-X10QBL-CT
    X10QBL-CT

Physical Stats

  • Form Factor
    Proprietary
  • Dimensions
    16.79″ x 16.4″ (42.65cm x 41.66cm)

Processor/Cache

  • CPU
    Intel Xeon processor E7-8800 v3, Intel Xeon processor E7-8800 v4.
    Quad Socket R (LGA 2011) supported, CPU TDP support 165W TDP, 1 QPI up to 9.6GT/s
  • Cores / Cache
    Up to 24 cores / Up to 60 MB cache

System Memory

  • Memory Capacity
    Up to 2TB 3DS ECC RDIMM, DDR3-1600MHz; Up to 2TB 3DS ECC LRDIMM, DDR3-1600MHz, in 32 DIMM slots
  • Memory Type
    1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
  • DIMM Sizes
    4GB, 8GB, 16GB, 32GB, 64GB
  • Memory Voltage
    1.35V, 1.5V
  • Error Detection
    Corrects single-bit errors
    Detects double-bit errors (using ECC memory)

On-Board Devices

  • Chipset
    Intel C602J
  • SATA
    SATA2 (3 Gbps) RAID 0,1,5,10
    SATA3 (6 Gbps) RAID 0,1JBOD support (IT Mode)
  • SAS
    SAS3 (12Gbps) via Broadcom 3008 controller SW RAID 0, 1, 10 support
  • IPMI
    Support for Intelligent Platform Management Interface v.2.0
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
    ASPEED AST2400 BMC
  • Network Controllers
    Dual LAN with Intel X540 10GBase-T Ethernet Controller X10QBL-CT Single LAN with Virtual Machine Device Queues reduce I/O overhead Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output Single LAN with Realtek RTL8211E PHY (dedicated IPMI)
  • Graphics
    Aspeed AST2400 BMC

Input / Output

  • SATA
    2 SATA3 (6Gbps) port
    4 SATA2 (3Gbps) ports
  • LAN
    2 RJ45 10GBase-T ports
    1 RJ45 Dedicated IPMI LAN port
  • USB
    6 USB 2.0 ports (3 rear + 2 headers + 1 Type A)
  • Video Output
    1 VGA port
  • Serial Port / Header
    2 COM Ports (1 rear, 1 header)
  • TPM
    1 TPM Header

Expansion Slots

  • PCI-E
    2 PCI-E 3.0 x16,
    2 PCI-E 3.0 x8,
    ,

System BIOS

  • BIOS Type
    128Mb SPI Flash EEPROM with AMI BIOS
  • BIOS Features
    Plug and Play (PnP)
    APM 1.2
    PCI 2.3
    ACPI 1.0 / 2.0 / 3.0 / 4.0
    USB Keyboard support
    SMBIOS 2.7.1
    UEFI 2.3.1

Management

  • Power Configurations
    ACPI Power Management
    Main Switch Override Mechanism
    CPU Fan auto-off in sleep mode
    Power-on mode for AC power recovery
Brand

Supermicro
BIOS Features

Plug and Play (PnP)APM 1.2PCI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportSMBIOS 2.7.1UEFI 2.3.1
Graphics

Aspeed AST2400 BMC
Serial Port / Header

1 header), 2 COM Ports (1 rear
TPM

1 TPM Header
PCI-E

2 PCI-E 3.0 x16, 2 PCI-E 3.0 x8
Network Controllers

Dual LAN with Intel X540 10GBase-T Ethernet Controller
Chipset

Intel C602J
DIMM Sizes

16GB, 32GB, 4GB, 64GB, 8GB
Cores / Cache

Up to 24 cores / Up to 60 MB cache
BIOS Type

128MB SPI Flash EEPROM with AMI BIOS
LAN

2 RJ45 10GBase-T ports1 RJ45 Dedicated IPMI LAN port
Video Output

1 VGA port
USB

6 USB 2.0 ports (3 rear + 2 headers + 1 Type A)
Form Factor

Proprietary
Memory Type

1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
Application

Server
IPMI

Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2400 BMC
Memory Voltage

1.35V, 1.5V
CPU

1 QPI up to 9.6GT/s, CPU TDP support 165W TDP, Intel Xeon processor E7-8800 v3, Intel Xeon processor E7-8800 v4.Quad Socket R (LGA 2011) supported
SAS

SAS3 (12Gbps) via Broadcom 3008 controller
SATA

2 SATA3 (6Gbps) port4 SATA2 (3Gbps) ports
Memory Capacity

DDR3-1600MHz, DDR3-1600MHz; Up to 2TB 3DS ECC LRDIMM, in 32 DIMM slots, Up to 2TB 3DS ECC RDIMM
Error Detection

Corrects single-bit errorsDetects double-bit errors (using ECC memory)
Dimensions

16.79" x 16.4" (42.65cm x 41.66cm)
