Supermicro MBD-X10QBL-4CT wholesale

* NOTE: Image may not exactly match the product

Supermicro MBD-X10QBL-4CT

The Supermicro MBD-X10QBL-4CT is a high-performance server motherboard designed for demanding enterprise applications. Built on the Intel C612 chipset, it supports dual Intel Xeon E5-2600 v3/v4 processors with up to 44 cores total, delivering exceptional computational power. Key features include 16 DDR4 DIMM slots supporting up to 1TB of registered ECC memory, four 10GbE LAN ports for high-speed networking, and comprehensive I/O expansion with multiple PCIe 3.0 slots. The board offers enterprise-grade reliability with IPMI 2.0 remote management, redundant power supply support, and advanced thermal monitoring. Its compact form factor maximizes density while maintaining robust cooling capabilities, making it ideal for data centers, virtualization environments, and high-performance computing applications requiring maximum processing power, memory capacity, and network throughput in a space-efficient design.

Quote1 Piece(MOQ)

BrandSupermicro
BIOS FeaturesPlug and Play (PnP)APM 1.2PCI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportSMBIOS 2.7.1UEFI 2.3.1
GraphicsAspeed AST2400 BMC
Serial Port / Header1 header), 2 COM Ports (1 rear
TPM1 TPM Header

Product SKUs

  • MBD-X10QBL-4CT
    X10QBL-4CT

Physical Stats

  • Form Factor
    Proprietary
  • Dimensions
    16.79″” x 16.4″” (42.65cm x 41.66cm)

Processor/Cache

  • CPU
    Intel Xeon processor E7-4800 v3, Intel Xeon processor E7-4800 v4, Intel Xeon processor E7-8800 v3, Intel Xeon processor E7-8800 v4.
    Quad Socket R (LGA 2011) supported, CPU TDP support 165W TDP, 1 QPI up to 9.6GT/s
  • Cores / Cache
    Up to 24 cores / Up to 60 MB cache

System Memory

  • Memory Capacity
    Up to 4TB 3DS ECC RDIMM, DDR4-1866MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-1866MHz, in 32 DIMM slots2TB DDR4 ECC LRDIMM
  • Memory Type
    1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin gold-plated DIMMs
  • DIMM Sizes
    RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB
    LRDIMM: 128GB
  • Memory Voltage
    1.2V
  • Error Detection
    Corrects single-bit errors

On-Board Devices

  • Chipset
    Intel C602J
  • SATA
    1 SATA2 (3 Gbps) ports; RAID 0,1,5,10
    1 SATA3 (6 Gbps) ports; RAID 0,1JBOD support (IT Mode)
  • SAS
    SAS3 (12Gbps) via LSI 3008 controller SW RAID 0, 1, 10 support
  • IPMI
    Support for Intelligent Platform Management Interface v.2.0
    IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
    ASPEED AST2400 BMC
  • Network Controllers
    Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output Single LAN with Virtual Machine Device Queues reduce I/O overhead Single LAN with Realtek RTL8211E PHY (dedicated IPMI) Single LAN with Intel X540 10GBase-T Ethernet Controller
  • Graphics
    Aspeed AST2400 BMC

Input / Output

  • SATA
    2 SATA3 (6Gbps) port
    4 SATA2 (3Gbps) ports
  • LAN
    2 RJ45 Gigabit Ethernet LAN ports
    1 RJ45 Dedicated IPMI LAN port
  • USB
    6 USB 2.0 ports (3 rear + 2 headers + 1 Type A)
  • Video Output
    1 VGA port
  • Serial Port / Header
    2 COM Ports (1 rear, 1 header)
  • TPM
    1 TPM Header

Expansion Slots

  • PCI-E
    2 PCI-E 3.0 x16,
    2 PCI-E 3.0 x8

System BIOS

  • BIOS Type
    128Mb SPI Flash EEPROM with AMI BIOS
  • BIOS Features
    Plug and Play (PnP)
    APM 1.2
    PCI 2.3
    ACPI 1.0 / 2.0 / 3.0 / 4.0
    USB Keyboard support
    SMBIOS 2.7.1
    UEFI 2.3.1

Management

  • Power Configurations
    ACPI Power Management
    Main Switch Override Mechanism
    CPU Fan auto-off in sleep mode
    Power-on mode for AC power recovery
Brand

Supermicro
BIOS Features

Plug and Play (PnP)APM 1.2PCI 2.3ACPI 1.0 / 2.0 / 3.0 / 4.0USB Keyboard supportSMBIOS 2.7.1UEFI 2.3.1
Graphics

Aspeed AST2400 BMC
Serial Port / Header

1 header), 2 COM Ports (1 rear
TPM

1 TPM Header
PCI-E

2 PCI-E 3.0 x16, 2 PCI-E 3.0 x8
Network Controllers

100BASE-TX, and 1000BASE-T, RJ45 output, Single LAN with Supports 10Base-T
Chipset

Intel C602J
DIMM Sizes

16GB, 32GB, 64GBLRDIMM: 128GB, 8GB, RDIMM: 4GB
Cores / Cache

Up to 24 cores / Up to 60 MB cache
BIOS Type

128MB SPI Flash EEPROM with AMI BIOS
LAN

2 RJ45 Gigabit Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port
Video Output

1 VGA port
USB

6 USB 2.0 ports (3 rear + 2 headers + 1 Type A)
Form Factor

Proprietary
Memory Type

1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin gold-plated DIMMs
Application

Server
IPMI

Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2400 BMC
Memory Voltage

1.2V
CPU

1 QPI up to 9.6GT/s, CPU TDP support 165W TDP, Intel Xeon processor E7-4800 v3, Intel Xeon processor E7-4800 v4, Intel Xeon processor E7-8800 v3, Intel Xeon processor E7-8800 v4.Quad Socket R (LGA 2011) supported
SAS

1, 10 support, SAS3 (12Gbps) via LSI 3008 controller SW RAID 0
SATA

2 SATA3 (6Gbps) port4 SATA2 (3Gbps) ports
Memory Capacity

DDR4-1866MHz, DDR4-1866MHz; Up to 4TB 3DS ECC LRDIMM, in 32 DIMM slots2TB DDR4 ECC LRDIMM, Up to 4TB 3DS ECC RDIMM
Error Detection

Corrects single-bit errors
Dimensions

16.79"" x 16.4"" (42.65cm x 41.66cm)
