| Brand | Supermicro |
|---|---|
| PCI-Express | 6 PCI-E 4.0 x16 slots |
| Graphics | ASPEED AST2600 BMCVGA connector is dedicated for IPMI |
| Cores | Up to 64 Cores |
| Audio | ALC4050H + ALC1220 7.1 Channel HD Audio |
| Network Controllers | 10G LAN: Single LAN via Marvell AQC113C 10Gb controller1GbE LAN: Single LAN via via Intel i210AT controller (shared with IPMI) |
| M.2 | 1, 10 support, 22110Key: M-keySoftware RAID 0, 5, Interface: 4 PCI-E 4.0 x4Form factor: 2280 |
| Chipset | AMD WRX80 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256MB Flash EEPROM |
| LAN | 1 RJ45 10GBase-T LAN port1 RJ45 GbE LAN port (shared with IPMI) |
| USB | 1 Type C header, 1 USB 3.2 Gen2x2 port (Type C, 1 via header)2 USB 2.0 via header, 10Gbps)5 USB 3.2 Gen1 ports (3 Type A, 20Gbps)5 USB 3.2 Gen2 ports (4 Type A |
| Form Factor | E-ATX |
| Memory Type | buffered and Un-buffered, ECC and Non-ECC, LRDIMM and 3DS R-DIMM MemoryDDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Mhz, R-DIMM, U-DIMM |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v.2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2600 BMC |
| Others | 1 COM port (rear)1 TPM 2.0 header |
| VGA | 1 VGA port (dedicated for IPMI) |
| Memory Voltage | 1.2V |
| CPU | Single AMD Ryzen Threadripper PRO 5000WX/3000WX Series ProcessorSocket sWRX8/SP3Supports CPU TDP up to 280W |
| SATA | 4 SATA3 (6 Gbps) ports |
| Memory Capacity | 8 DIMM slotsECC and Non-ECC, buffered and Un-buffered, LRDIMM and 3DS R-DIMM MemoryRDIMM up to 2TB, R-DIMM, U-DIMM, UDIMM up to 256GB8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 12" x 13" (30.48cm x 33.02cm) |
| U.2 | 1 support, Interface: 2 U.2 SocketsSoftware RAID 0 |
* NOTE: Image may not exactly match the product
Supermicro MBD-M12SWA-TF
The Supermicro MBD-M12SWA-TF is a high-performance Mini-ITX motherboard designed for edge computing and compact server applications. Built around the Intel Atom x6000E series processors, it delivers exceptional power efficiency while maintaining enterprise-grade reliability. Key features include dual 10GbE networking ports for high-speed connectivity, multiple PCIe slots for expansion flexibility, and comprehensive I/O options including USB 3.2 and SATA interfaces. The board supports up to 32GB DDR4 memory and features Supermicro’s advanced thermal management for optimal performance in space-constrained environments. Its compact form factor, industrial-grade components, and extended temperature range operation make it ideal for IoT gateways, network appliances, and embedded systems requiring robust performance in minimal space. The motherboard’s unique value lies in combining server-class features with ultra-compact design, enabling powerful computing solutions for edge deployments where space and power consumption are critical considerations.
Quote1 Piece(MOQ)
Bulk Order Discounts Available
| Brand | Supermicro |
|---|---|
| PCI-Express | 6 PCI-E 4.0 x16 slots |
| Graphics | ASPEED AST2600 BMCVGA connector is dedicated for IPMI |
| Cores | Up to 64 Cores |
| Audio | ALC4050H + ALC1220 7.1 Channel HD Audio |
