| Brand | Supermicro |
|---|---|
| BIOS Features | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
| Audio | ALC 888S HD Audio |
| TPM | 1 TPM Header |
| Network Controllers | Dedicated LAN for IPMI, Dual LAN with Intel i210 Gigabit Ethernet ControllerSingle LAN with ASPEED AST2600 BMC |
| M.2 | M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1Form Factor: 2280/22110Key: M-Key |
| Chipset | B650 |
| DIMM Sizes | 16GB, 24GB, 32GB, 48GB, 8GB |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Video Output | 1 DP 1.4a port(s), 1 HDMI 2.0 port(s), 2 rear type C port(s) DP 1.4 Alt mode |
| Dimension | 9.6" x 9.6" (24.384cm x 24.384cm) |
| PCIe | 1 PCIe 4.0 x4, 2 PCIe 5.0 x16 slots (16/NA or 8/8) |
| Form Factor | Micro-ATX |
| Memory Type | 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC) |
| Application | Server |
| IPMI | ASPEED AST2600 BMC |
| Memory Voltage | 1.1V |
| CPU | AMD EPYC 4004 series ProcessorsSingle Socket LGA-1718 (Socket AM5) supported, CPU TDP supports Up to 170W TDP |
| Serial Port | 1 COM Port(s) (1 header) |
| SATA | 1, 10, 4 SATA3 ports; RAID 0 |
| Memory Capacity | 4 DIMM slots |
| Core | 32 threads, Up to 16 cores |
* NOTE: Image may not exactly match the product
Supermicro MBD-H13SAE-MF-B
The Supermicro MBD-H13SAE-MF-B is a high-performance server motherboard featuring the AMD SP5 socket for 4th Gen EPYC processors, delivering exceptional computing power for enterprise workloads. Key features include support for up to 12 DDR5 memory channels with speeds up to 4800MHz, providing massive memory bandwidth and capacity. The board offers robust I/O connectivity with multiple PCIe 5.0 slots, dual 10GbE networking, and comprehensive storage options including M.2 NVMe support. Built with Supermicro’s renowned reliability and energy efficiency, it includes advanced thermal management, remote management capabilities via IPMI, and enterprise-grade security features. This motherboard excels in data centers, virtualization environments, and high-performance computing applications where maximum processing power, memory capacity, and system reliability are critical requirements.
Quote1 Piece(MOQ)
Bulk Order Discounts Available
| Brand | Supermicro |
|---|---|
| BIOS Features | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
| Audio | ALC 888S HD Audio |
| TPM | 1 TPM Header |
| Network Controllers | Dedicated LAN for IPMI, Dual LAN with Intel i210 Gigabit Ethernet ControllerSingle LAN with ASPEED AST2600 BMC |
