| Brand | Supermicro |
|---|---|
| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 5.1USB Keyboard SupportSMBIOS 3.1.1 |
| PCI-Express | 1 PCI-E 4.0 x32 Left Riser Slot1 PCI-E 4.0 x16 Right Riser Slot |
| Cores | Up to 64 Cores |
| Network Controllers | Dual GbE LAN Ports via Broadcom BCM57201 Realtek RTL8211F PHY (dedicated IPMI) |
| M.2 | 22110Key: M-Key, Interface: 2 PCI-E 4.0 x2Form Factor: 2280 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | 2 RJ45 GbE LAN ports1 RJ45 Dedicated IPMI LAN port |
| NVMe | 12 NVMe (PCI-E Gen4) |
| USB | 1 Type A), 2 via header, 7 USB 3.0 ports (4 rear |
| Form Factor | Proprietary |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2500 BMC |
| Others | 1 COM port2 SuperDOM power connectors1 TPM 1.2/2.0 header |
| VGA | 1 VGA port |
| SATA/NVMe Hybrid | 16 SATA3 or 4 NVMe via SlimSAS (PCI-E Gen4) |
| Memory Voltage | 1.2V |
| CPU | Single AMD EPYC 7003/7002 Series ProcessorSocket SP3 |
| SATA | 2 SATA3 (6 Gbps) ports |
| Memory Capacity | 16 DIMM slotsSupports up to 4TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 13.4" x 12.29" (34cm x 31.2cm) |
* NOTE: Image may not exactly match the product
Supermicro MBD-H12SSW-iNR
The Supermicro MBD-H12SSW-iNR is a high-performance mini-ITX server motherboard designed for compact yet powerful computing solutions. Built around the AMD EPYC 7002/7003 series processors, it delivers enterprise-grade performance in an ultra-compact form factor. Key features include support for up to 1TB of DDR4 ECC memory across four DIMM slots, dual 10GbE networking ports for high-speed connectivity, and comprehensive I/O including USB 3.0, SATA 6Gb/s, and M.2 NVMe storage support. The board features IPMI 2.0 with dedicated management LAN for remote monitoring and control, making it ideal for edge computing, small office deployments, and space-constrained data center applications. Its unique selling proposition lies in combining full server-class capabilities with AMD EPYC’s exceptional performance-per-watt ratio in the industry’s smallest server form factor, enabling powerful computing solutions where space and energy efficiency are critical.
Quote1 Piece(MOQ)
Bulk Order Discounts Available
