| Brand | Supermicro |
|---|---|
| BIOS Features | Plug and Play (PnP)DMI 2.3PCI 2.2ACPI 6.2USB Keyboard SupportSMBIOS 3.1.1 |
| PCI-Express | 3 PCI-E 4.0 x16 Riser Slots9 PCI-E 4.0 x8 SlimSAS2 PCI-E 4.0 x4 SlimSAS1 PCI-E 4.0 x16 AIOM LAN Networking Slot |
| Cores | Up to 64 Cores |
| Network Controllers | LAN Networking provided via AIOMDedicated IPMI via Realtek RTL8211F PHY |
| M.2 | 22110Key: M-Key, 2260, 2280, Interface: 2 PCI-E 4.0 x4Form Factor: 2242 |
| DIMM Sizes | 128GB, 16GB, 256GB, 32GB, 64GB, 8GB |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| LAN | Provided via AIOM1 RJ45 Dedicated IPMI LAN port |
| NVMe | 2 NVMe via SlimSAS |
| USB | 2 USB 3.0 ports (rear) |
| Form Factor | Proprietary |
| Memory Type | 288-pin gold-plated DIMMs, DDR4 3200 MHz Registered ECC |
| Application | Server |
| IPMI | Support for Intelligent Platform Management Interface v. 2.0IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportASPEED AST2600 BMC |
| Others | 1 COM port (header)1 TPM 1.2/2.0 header |
| VGA | 1 VGA port (rear) |
| Memory Voltage | 1.2V |
| CPU | Single AMD Ryzen Threadripper PRO 5000WX/3000WX Series ProcessorSocket SP3 |
| Memory Capacity | 8 DIMM slotsSupports up to 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs8-channel memory bus |
| Error Detection | Corrects single-bit errorsDetects double-bit errors (using ECC memory) |
| Dimensions | 9.6" x 14.5" |
* NOTE: Image may not exactly match the product
Supermicro MBD-H12SSG-ANP6
The Supermicro MBD-H12SSG-ANP6 is a high-performance server motherboard designed for demanding enterprise applications. Built on the AMD SP5 socket, it supports 4th Gen AMD EPYC processors with up to 96 cores, delivering exceptional computational power. Key features include 12 DDR5 DIMM slots supporting up to 3TB of memory, dual 10GbE LAN ports for high-speed networking, and comprehensive storage connectivity with multiple SATA and NVMe slots. The board offers robust expansion capabilities with multiple PCIe 5.0 slots, advanced thermal management, and enterprise-grade reliability features including IPMI 2.0 for remote management. Its compact ATX form factor makes it ideal for 1U/2U rack servers, while supporting virtualization, cloud computing, and high-performance computing workloads. The motherboard’s unique selling points include its exceptional memory capacity, cutting-edge DDR5 support, and Supermicro’s proven track record in server-grade hardware reliability and performance optimization.
Quote1 Piece(MOQ)
Bulk Order Discounts Available
