Supermicro MBD-H11SSL-I-B

The Supermicro MBD-H11SSL-I-B is a high-performance mini-ITX server motherboard designed for AMD EPYC 7001/7002 series processors, delivering enterprise-grade computing power in an ultra-compact form factor. This board supports up to 128GB of DDR4 ECC memory across four DIMM slots, ensuring reliable data integrity for mission-critical applications. Key features include dual 10GbE LAN ports for high-speed networking, PCIe 3.0 expansion slots, multiple SATA 6Gb/s connectors, and comprehensive IPMI 2.0 remote management capabilities. The motherboard excels in space-constrained environments while maintaining full server-class functionality, making it ideal for edge computing, micro data centers, and high-density deployments. Its unique selling proposition lies in combining AMD EPYC’s exceptional multi-core performance with Supermicro’s proven server reliability in the smallest possible footprint, offering up to 32 cores of processing power while consuming minimal rack space and power.

Quote1 Piece(MOQ)

Inquiry

Chipset	AMD SP3 Series
Products Status	New
Form Factor	ATX
Brand	Supermicro
USB Ports	5 USB 3.0 ports (2 rear + 2 via header + 1 Type A) 4 USB 2.0 ports (2 rear + 2 via header)

Additional information

Chipset	AMD SP3 Series
Products Status	New
Form Factor	ATX
Brand	Supermicro
USB Ports	5 USB 3.0 ports (2 rear + 2 via header + 1 Type A) 4 USB 2.0 ports (2 rear + 2 via header)
CPU Socket Type	AMD SP3(LGA 4094)
Warranty	1 Year
Internal I/O Connectors	Expansion slots: 3 PCI-E 3.0 x16 3 PCI-E 3.0 x8 M.2 Interface: 1 PCI-E 3.0 x4 M.2 Form Factor: 2280, 22110 M.2 Key: M-key 4.16 SATA3, 1 M.2 5.Dual Gigabit Ethernet LAN Ports 6.ASPEED AST2500 BMC graphics
Product Name	Supermicro MBD-H11SSL-I-B
Packaging Details	Bulk
Size	30.5cmx24.4cm
Memory	1TB Registered ECC DDR4 2666MHz SDRAM in 8 DIMMs 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs (Board revision 2.x required)
CPU Brand	AMD
Application	Server
