* NOTE: Image may not exactly match the product

Supermicro MBD-B2SD2-8C-TF

The Supermicro MBD-B2SD2-8C-TF is a compact, energy-efficient motherboard designed for edge computing and IoT applications. Built on Intel’s Atom C3000 series processor, it delivers reliable performance in a small form factor while consuming minimal power. Key features include dual 10GbE networking ports for high-speed connectivity, support for up to 128GB DDR4 memory, multiple storage options including M.2 and SATA interfaces, and comprehensive I/O connectivity. The board operates fanlessly in temperatures up to 60°C, making it ideal for harsh environments. Its unique selling points are the combination of enterprise-grade reliability, low power consumption (under 25W TDP), extensive networking capabilities, and Supermicro’s proven track record in server-grade hardware – all packaged in a cost-effective solution perfect for network appliances, industrial automation, and distributed computing deployments.

Quote1 Piece(MOQ)

Premium Client Discounts Available

BrandSupermicro
BIOS FeaturesACPI 6.1UEFI 2.7SMBIOS 2.8SMBIOS 3.1PCI FW 3.2Plug and Play (PnP)
Graphics1 ASPEED AST2500 BMC port(s)
TPM1 TPM Header & Chip both
Network ControllersDual LAN with SoC, Two(2)10GbE Ethernet ports from KR interface to BP

Product SKUs

  • MBD-B2SD2-8C-TF

Physical Stats

  • Form Factor
    Proprietary
  • Dimension
    4.803″ x 17.086″ (12.2cm x 43.39cm)

Processor

  • CPU
    Intel Xeon Processor D-2141I, Intel Xeon D Processor (Skylake-D)
    Single Socket FCBGA-2518 supported, CPU TDP supports Up to 65W TDP
  • Core
    Up to 8 cores, 16 threads / 11MB Cache

System Memory

  • Memory Capacity
    4 DIMM slots
    Up to 128GB ECC RDIMM, DDR4-2133MT/s
  • Memory Type
    2133/2400 MT/s ECC DDR4 RDIMM VLP
  • DIMM Sizes
    8GB, 16GB, 32GB
  • Memory Voltage
    1.2V

On-Board Devices

  • Chipset
    System on Chip
  • IPMI
    ASPEED AST2500
  • Graphics
    1 ASPEED AST2500 BMC port(s)
  • Network Controllers
    Dual LAN with SoC, Two(2)10GbE Ethernet ports from KR interface to BP

Input / Output

  • SATA
    1 SATA3 (6Gbps) port(s)
  • DOM
    1 SATA DOM (Disk on Module) power connector support
  • TPM
    1 TPM Header & Chip both

Expansion Slots

  • PCIe
    1 PCIe 3.0 x4
  • M.2
    M.2 Interface: 1 PCIe 3.0 x4
    Form Factor: 2242/2280/22110
    Key: M-Key

System BIOS

  • BIOS Type
    256MB SPI Flash with AMI BIOS
  • BIOS Features
    ACPI 6.1
    UEFI 2.7
    SMBIOS 2.8
    SMBIOS 3.1
    PCI FW 3.2
    Plug and Play (PnP)

Management

  • System Management Software
    IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
  • Power Configurations
    +12V DC Power Input
Brand

Supermicro

BIOS Features

ACPI 6.1UEFI 2.7SMBIOS 2.8SMBIOS 3.1PCI FW 3.2Plug and Play (PnP)

Graphics

1 ASPEED AST2500 BMC port(s)

TPM

1 TPM Header & Chip both

Network Controllers

Dual LAN with SoC, Two(2)10GbE Ethernet ports from KR interface to BP

M.2

M.2 Interface: 1 PCIe 3.0 x4Form Factor: 2242/2280/22110Key: M-Key

Chipset

System on Chip

DIMM Sizes

16GB, 32GB, 8GB

BIOS Type

256MB SPI Flash with AMI BIOS

DOM

DOM

Dimension

4.803" x 17.086" (12.2cm x 43.39cm)

PCIe

1 PCIe 3.0 x4

Form Factor

Proprietary

Memory Type

2133/2400 MT/s ECC DDR4 RDIMM VLP

Application

Server

IPMI

ASPEED AST2500

Memory Voltage

1.2V

CPU

CPU TDP supports Up to 65W TDP, Intel Xeon D Processor (Skylake-D)Single Socket FCBGA-2518 supported, Intel Xeon Processor D-2141I

SATA

1 SATA3 (6Gbps) port(s)

Memory Capacity

4 DIMM slotsUp to 128GB ECC RDIMM, DDR4-2133MT/s

Core

16 threads / 11MB Cache, Up to 8 cores
