* NOTE: Image may not exactly match the product

Supermicro MBD-B2SC2-TF

The Supermicro MBD-B2SC2-TF is a compact Mini-ITX server motherboard designed for space-constrained environments requiring reliable server-grade performance. Built around Intel’s Atom processor platform, it delivers exceptional power efficiency while maintaining enterprise-level features including dual Gigabit Ethernet ports, multiple USB connections, and comprehensive I/O options. The board features integrated graphics, supports up to 8GB DDR3 memory, and includes IPMI 2.0 for remote management capabilities. Its fanless design ensures silent operation, making it ideal for edge computing, IoT gateways, network appliances, and embedded applications where low power consumption, minimal heat generation, and 24/7 reliability are critical. The motherboard’s industrial-grade components and Supermicro’s proven server heritage provide enterprise durability in an ultra-compact form factor.

Quote1 Piece(MOQ)

Inquiry

Brand	Supermicro
BIOS Features	ACPI 6.1UEFI 2.7SMBIOS 2.8SMBIOS 3.1PCI FW 3.2Plug and Play (PnP)
Graphics	1 ASPEED AST2500 BMC port(s)
TPM	1 TPM Header
Network Controllers	Dual LAN with 10Gbase-T, Two(2)10GbE Ethernet ports from KR interface to BP

Description
Additional information

Product SKUs

MBD-B2SC2-TF

Physical Stats

Form Factor
Proprietary
Dimension
4.8″ x 17″ (12.19cm x 43.18cm)

Processor

CPU
Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor
Dual Socket Socket H4 (LGA-1151) supported, CPU TDP supports Up to 95W TDP
Core
Up to 8 cores

System Memory

Memory Capacity
2 DIMM slots
Up to 64GB ECC/non-ECC , DDR4-2666MT/s
Up to 64GB ECC VLP UDIMM DDR4-2666Mhz support in 2 DIMM slots per node
Memory Type
64GB DDR4-2666MHz in 4 DIMM slots
DIMM Sizes
8GB, 16GB, 32GB, 64GB
Memory Voltage
1.2V

On-Board Devices

Chipset
Intel C246
IPMI
ASPEED AST2500
Graphics
1 ASPEED AST2500 BMC port(s)
Network Controllers
Dual LAN with 10Gbase-T, Two(2)10GbE Ethernet ports from KR interface to BP

Input / Output

DOM
1 SATA DOM (Disk on Module) power connector support
TPM
1 TPM Header
Others
1 SATA DOM and TPM header per node

Expansion Slots

PCIe
2x U.2 (PCIex4 only) via backplane per node

System BIOS

BIOS Type
128MB SPI Flash EEPROM with AMI BIOS
BIOS Features
ACPI 6.1
UEFI 2.7
SMBIOS 2.8
SMBIOS 3.1
PCI FW 3.2
Plug and Play (PnP)

Management

System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
Power Configurations
+12V DC Power Input

Brand	Supermicro
BIOS Features	ACPI 6.1UEFI 2.7SMBIOS 2.8SMBIOS 3.1PCI FW 3.2Plug and Play (PnP)
Graphics	1 ASPEED AST2500 BMC port(s)
TPM	1 TPM Header
Network Controllers	Dual LAN with 10Gbase-T, Two(2)10GbE Ethernet ports from KR interface to BP
Chipset	Intel C246
DIMM Sizes	16GB, 32GB, 64GB, 8GB
BIOS Type	128MB SPI Flash EEPROM with AMI BIOS
DOM	DOM
Dimension	4.8" x 17" (12.19cm x 43.18cm)
PCIe	2x U.2 (PCIex4 only) via backplane per node
Form Factor	Proprietary
Memory Type	64GB DDR4-2666MHz in 4 DIMM slots
Application	Server
IPMI	ASPEED AST2500
Others	1 SATA DOM and TPM header per node
Memory Voltage	1.2V
CPU	CPU TDP supports Up to 95W TDP, Intel Xeon E-2100 Processor, Intel Xeon E-2200 ProcessorDual Socket Socket H4 (LGA-1151) supported
Memory Capacity	2 DIMM slotsUp to 64GB ECC/non-ECC, DDR4-2666MT/sUp to 64GB ECC VLP UDIMM DDR4-2666Mhz support in 2 DIMM slots per node
Core	Up to 8 cores
