* NOTE: Image may not exactly match the product

Supermicro MBD-B11SRE-CPU-TF

The Supermicro MBD-B11SRE-CPU-TF is a high-performance embedded server motherboard featuring an integrated AMD EPYC 7003 series processor. This compact yet powerful solution delivers enterprise-grade computing in a space-efficient design, supporting up to 1TB of DDR4 ECC memory across 8 DIMM slots. Key features include dual 10GbE networking, multiple PCIe 4.0 expansion slots, comprehensive I/O connectivity with USB 3.0 and serial ports, and advanced server management through IPMI 2.0. The board supports NVMe storage and offers exceptional reliability with ECC memory support and enterprise-grade components. Ideal for edge computing, virtualization, and high-density server deployments, it combines the processing power of AMD’s latest EPYC architecture with Supermicro’s proven server expertise, delivering exceptional performance-per-watt efficiency in applications requiring compact form factors without compromising on enterprise features.

Quote1 Piece(MOQ) Minimum Order Quantity

Inquiry

Brand	Supermicro
Application	Server
Form Factor	Proprietary
Chipset	Intel C422
Products Status	New

Description
Additional information

Product SKUs

MBD-B11SRE-CPU-TF

Physical Stats

Form Factor
Proprietary
Dimension
9.358″ x 11.606″ (23.77cm x 29.48cm)

Processor

CPU
Intel Xeon Processor W Family
Single Socket Socket R4 (LGA-2066) supported

System Memory

Memory Capacity
8 DIMM slots
Up to 512GB ECC LRDIMM; Up to 256GB ECC RDIMM
Memory Type
2666/2400/2133 MT/s ECC LRDIMM, RDIMM
DIMM Sizes
8GB, 16GB, 32GB, 64GB
Memory Voltage
1.2V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)

On-Board Devices

Chipset
Intel C422
IPMI
ASPEED AST2500
Graphics
1 ASPEED AST2500 BMC port(s)
Network Controllers
Dual LAN, Two(2)10GbE Ethernet ports from KR interface to BP

Input / Output

SATA
1 SATA3 (6Gbps) port(s)
DOM
1 SATA DOM (Disk on Module) power connector support
TPM
1 TPM Header

Expansion Slots

PCIe
PCIe x16 Expansion for Various I/O Modules

System BIOS

BIOS Type
128MB SPI Flash EEPROM with AMI BIOS
BIOS Features
ACPI 6.1
UEFI 2.7
SMBIOS 2.8
Plug and Play (PnP)

Management

System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support

Brand	Supermicro
Application	Server
Form Factor	Proprietary
Chipset	Intel C422
Products Status	New
Socket	LGA-3647
BIOS Type	128MB SPI Flash EEPROM with AMI BIOS
Memory Capacity	8 DIMM slotsUp to 512GB ECC LRDIMM; Up to 256GB ECC RDIMM
Memory Type	2666/2400/2133 MT/s ECC LRDIMM, RDIMM
Memory Voltage	1.2V
DIMM Sizes	16GB, 32GB, 64GB, 8GB
CPU	Intel Xeon Processor W FamilySingle Socket Socket R4 (LGA-2066) supported
Error Detection	Corrects single-bit errorsDetects double-bit errors (using ECC memory)
SATA	1 SATA3 (6Gbps) port(s)
Dimension	9.358" x 11.606" (23.77cm x 29.48cm)
Network Controllers	Dual LAN, Two(2)10GbE Ethernet ports from KR interface to BP
IPMI	ASPEED AST2500
PCIe	PCIe x16 Expansion for Various I/O Modules
TPM	1 TPM Header
BIOS Features	ACPI 6.1UEFI 2.7SMBIOS 2.8Plug and Play (PnP)
Graphics	1 ASPEED AST2500 BMC port(s)
