Supermicro MBD-B11SPE-CPU-TF

The Supermicro MBD-B11SPE-CPU-TF is a high-performance embedded server motherboard featuring an integrated AMD EPYC 7003 series processor. This compact Mini-ITX form factor board delivers enterprise-grade computing power with up to 64 cores, 8 DDR4 memory slots supporting up to 2TB RAM, and dual 10GbE networking ports. Key advantages include exceptional processing density for space-constrained environments, enterprise reliability with ECC memory support, comprehensive I/O connectivity including PCIe 4.0 slots, and energy-efficient operation. The board’s integrated CPU design eliminates compatibility concerns while providing superior performance-per-watt ratios, making it ideal for edge computing, network appliances, storage systems, and high-density server deployments where maximum computing power in minimal space is essential.

Quote1 Piece(MOQ)

Inquiry

Brand	Supermicro
BIOS Features	ACPI 6.1UEFI 2.7SMBIOS 2.8Plug and Play (PnP)
Graphics	1 ASPEED AST2500 BMC port(s)
TPM	1 TPM Header
Network Controllers	Dual LAN, Two(2)10GbE Ethernet ports from KR interface to BP

Description
Additional information

Product SKUs

MBD-B11SPE-CPU-TF

Physical Stats

Form Factor
Proprietary
Dimension
9.358″ x 11.606″ (23.77cm x 29.48cm)

Processor

CPU
2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable Processors
Single Socket Socket P (LGA-3647) supported
Core
Up to 28 cores

System Memory

Memory Capacity
12 DIMM slots
Up to 3TB ECC LRDIMM; Up to 3TB ECC RDIMM
Memory Type
3200/2933/2666 MT/s ECC LRDIMM, RDIMM
DIMM Sizes
LRDIMM: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
RDIMM: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage
1.2V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)

On-Board Devices

Chipset
Intel C622
IPMI
ASPEED AST2500
Graphics
1 ASPEED AST2500 BMC port(s)
Network Controllers
Dual LAN, Two(2)10GbE Ethernet ports from KR interface to BP

Input / Output

SATA
1 SATA3 (6Gbps) port(s)
DOM
1 SATA DOM (Disk on Module) power connector support
TPM
1 TPM Header

Expansion Slots

PCIe
PCIe x16 Expansion for Various I/O Modules

System BIOS

BIOS Type
128MB SPI Flash EEPROM with AMI BIOS
BIOS Features
ACPI 6.1
UEFI 2.7
SMBIOS 2.8
Plug and Play (PnP)

Management

System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support

Brand	Supermicro
BIOS Features	ACPI 6.1UEFI 2.7SMBIOS 2.8Plug and Play (PnP)
Graphics	1 ASPEED AST2500 BMC port(s)
TPM	1 TPM Header
Network Controllers	Dual LAN, Two(2)10GbE Ethernet ports from KR interface to BP
Chipset	Intel C622
DIMM Sizes	128GB, 16GB, 256GB, 256GBRDIMM: 8GB, 32GB, 64GB, LRDIMM: 8GB
BIOS Type	128MB SPI Flash EEPROM with AMI BIOS
DOM	DOM
Dimension	9.358" x 11.606" (23.77cm x 29.48cm)
PCIe	PCIe x16 Expansion for Various I/O Modules
Form Factor	Proprietary
Memory Type	3200/2933/2666 MT/s ECC LRDIMM, RDIMM
Application	Server
IPMI	ASPEED AST2500
Memory Voltage	1.2V
CPU	2nd Gen Intel Xeon Scalable Processors and Intel Xeon Scalable ProcessorsSingle Socket Socket P (LGA-3647) supported
SATA	1 SATA3 (6Gbps) port(s)
Memory Capacity	12 DIMM slotsUp to 3TB ECC LRDIMM; Up to 3TB ECC RDIMM
Error Detection	Corrects single-bit errorsDetects double-bit errors (using ECC memory)
Core	Up to 28 cores
