* NOTE: Image may not exactly match the product

Seagate BarraCuda 7200.7 – 80.0GB 7200RPM Ultra ATA-100 2MB Cache 3.5″ Desktop Hard Drive – ST380011A

The Seagate BarraCuda 7200.7 ST380011A delivers reliable desktop storage with 80GB capacity and 7200RPM performance for faster data access and application loading. This 3.5-inch drive features Ultra ATA-100 interface for efficient data transfer and includes 2MB cache to optimize read/write operations. Built with Seagate’s proven BarraCuda reliability, it offers cost-effective storage expansion for older desktop systems, legacy applications, and budget-conscious users seeking dependable performance. The drive’s mature technology ensures compatibility with a wide range of systems while providing the essential storage capacity needed for basic computing tasks, file storage, and system operations.

Quote50 pcs(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

InterfacePATA (EIDE Ultra ATA-6)
Advanced FormatNo
Capacity80GB
Workload Rating<55 TB/yr (Workload Rate Limit) / 50,000 (Start/Stop Cycles)
Interface ConnectorPATA (40-Pin Signal and 4-Pin Power Connector)

Barracuda 7200.7 is the latest in the Seagate 3.5-inch family of high-capacity desktop drives targeted at mainstream and high-performance PCs and advanced storage applications. The product enables OEMs and system builders to qualify one family of drives from a premier provider for a wide range of storage applications.

The Seagate Advantage

High capacity Barracuda 7200.7 disc drives, from the worlds premier provider of high-capacity storage, provide our customers years of reliable service and high performance. Using advanced manufacturing techniques and extensive design experience, Seagate engineers have built the worlds only seventh-generation 7200-RPM desktop disc drive. In addition, Seagate PATA Ultra ATA/100 Barracuda disc drives enable bigger profit margins for system builders with enhanced reliability, higher performance and innovative features..

Key Features and Benefits

  • Highest available capacityup to 200 Gbytes, enabling OEMs and system builders to qualify one family of drives for a wide range of personal storage, entry-level server and fixed-content storage applications.
  • Ultra ATA/100 provides coverage of all applications.
  • A proven design for shorter qualification times and top reliability.
  • Whisper-quiet acoustics for a nearly silent drive.
  • Seagate SoftSonic motor enables whisper-quiet operation.
  • Advanced manufacturing and latest technology for the most reliable storage solutions ever.
  • The industrys most comprehensive compatibility and benchmark testing.



Interface

PATA (EIDE Ultra ATA-6)

Advanced Format

No

Capacity

80GB

Workload Rating

<55 TB/yr (Workload Rate Limit) / 50,000 (Start/Stop Cycles)

Interface Connector

PATA (40-Pin Signal and 4-Pin Power Connector)

Form Factor

3.5"

Application

Desktop

Brand

Seagate

Shock Resistance

Operating: 63Gs (2ms) / Non Operating: 350Gs (2ms)

Life Expectancy

600,00 Hours MTBF (Mean Time Before Failures)

Encryption

No

Data Transfer Rate

32MB/sec to 58MB/sec Host to/from Drive (Sustained)

Recording Technology

Perpendicular Giant Magnetoresistive Recording (GMR) Technology

Cache

2MB

Products Status

New

Interface Speed

Ultra ATA 100MB/s

RPM

7200 RPM

Rohs Compliant

Yes
