SAMSUNG 970 EVO PLUS M.2 2280 250GB PCIe Gen 3.0 x4, NVMe 1.3 V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-V7S250BW

SamSung PM981A/970 EVO plus 250GB M.2 2280 NVME PCIe 3.0 x4 MZ-V7S250BW

Quote5 pcs(MOQ)

Height2.38mm
Width22.15mm
Used ForConsumer
Device TypeInternal Solid State Drive (SSD)
BrandSamSung

Height

2.38mm

Width

22.15mm

Used For

Consumer

Device Type

Internal Solid State Drive (SSD)

Brand

SamSung

Capacity

250GB

Cache

Samsung 512MB Low Power DDR4 SDRAM

Controller

Samsung Phoenix

Max Shock Resistance

1 500G & 0.5 ms (Half sine)

Products Status

New

Depth

80.15mm

Application

Desktop

Series

Samsung 970 EVO PLUS

Interface

PCIe 3.0 x4 NVMe 1.3

Max Sequential Write

Up to 2300 MB/s

Features

Always Evolving SSD, Design Flexibility, Exceptional Endurance, Level up Performance, Reliability: 150 TBW, Samsung Magician, The new standard in sustainable performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung's reputation for quality., Unparalleled Reliability

Max Sequential Read

Up to 3500 MB/s

Power Consumption (Idle)

Max. 30 mW

4KB Random Write

QD1: Up to 60 000 IOPS, QD32: Up to 550 000 IOPS

MTBF

1 500 000 hours

Model

MZ-V7S250BW

Operating Temperature

0C ~ +70C

Power Consumption (Active)

Average: 5W, Maximum: 8W (Burst mode)

Weight

8.00g

Form Factor

M.2 2280

Memory Components

V-NAND 3-bit MLC

4KB Random Read

QD1: Up to 17 000 IOPS, QD32: Up to 250 000 IOPS
