SAMSUNG 980 M.2 2280 500GB PCI-Express 3.0 x4, NVMe 1.4 V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-V8V500BW

Brand

SamSung

Products Status

New

Model

MZ-V8V500BW

Used For

Consumer

Application

Desktop

SSD 980: Versatile, High-Performance PCIe 3.0 SSD

Samsung’s 980 500GB Solid State Drive transcends your machine’s performance and responsiveness. Boasting high transfer speeds and excellent endurance, the Samsung 980 in M.2 2280 form factor relies on the PCI-E 3.0 x4 interface as well as NVMe technology. It is also equipped with a Samsung V-NAND 3-bit MLC memory and a Samsung Pablo controller.

The Samsung 980 M.2 PCIe 3.0 4x NVMe is ideal for users looking for a high-performance PCIe 3.0 x4 SSD. Its high-performance throughputs for heavy-duty gaming, computer graphics, data analysis, and more rediscover fluidity and responsiveness in any task.

ACCESS 3.0 PERFORMANCE

Bring your gear into a new era with the power of the Samsung 980 NVMe PCIe 3.0 SSD. The 980 makes it possible to exploit the PCIe 3.0 interface to its limits. The 980 has been optimized for speed thanks to its Samsung Pablo controller, specially designed for this SSD.

PRECISE THERMAL CONTROL

High-performance SSDs require extremely tight thermal control. To ensure the most stable performance, the 980 is equipped with a controller protected by nickel to allow it to maintain a stable temperature, and a heat sink which will protect the NAND chip from all temperature variations.

Samsung has equipped the 980 with an advanced algorithm so that the SSD itself can manage its temperature peaks and therefore ensure stable performance. To minimize long-term speed variations, Samsung’s Dynamic Thermal Guard technology keeps the 980’s temperature at an optimal level.

SAMSUNG MAGICIAN

Access the true power of the 980 thanks to the Samsung Magician software and its intuitive tools: monitor the state of the disk, optimize its performance, protect your important data, and receive all the updates to always benefit from the best possible performance with your SSD .

Brand	SamSung
Products Status	New
Model	MZ-V8V500BW
Used For	Consumer
Application	Desktop
Capacity	500GB
Form Factor	M.2 2280
Memory Components	V-NAND 3-bit MLC
Max Sequential Read	Up to 3100 MB/s
4KB Random Read	QD1: 17 000 IOPS, QD32: 400 000 IOPS
4KB Random Write	QD1: 54 000 IOPS, QD32: 470 000 IOPS
Depth	80.15mm
Max Shock Resistance	1 500G & 0.5 ms (Half sine)
Width	22.15mm
Power Consumption (Active)	Average: 4.3W, Maximum: 5.9W (Burst mode)
