| Brand | Intel |
|---|---|
| Products Status | New |
| Series | Intel Xeon E3 v6 |
| Part Number | E3-1240V6 |
| Model | CM8067702870649 |
| Application | Server |
| CPU Socket Type | FCLGA1151 |
| Code Name | Products formerly Kaby Lake |
| Total Cores | 4 |
| Total Threads | 8 |
| Max Turbo Frequency | 4.10 GHz |
| Processor Base Frequency | 3.70 GHz |
| Cache | 8 MB Intel Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 72 W |
| Manufacturing Tech | 14 nm |
| 64-Bit Support | Yes |
| Hyper-Threading Support | Yes |
| Embedded Options Available | No |
| Max Memory Size | 64 GB |
| Memory Types | DDR3L-1866, DDR4-2400 |
| Max # of Memory Channels | 2 |
| ECC Memory Supported | Yes |
| Scalability | 1S Only |
| PCI Express Revision | 3 |
| PCI Express Configurations | 1×16, 1×8+2×4, 2×8 |
| Max # of PCI Express Lanes | 16 |
| Max CPU Configuration | 1 |
| Instruction Set | 64-bit |
| Graphics Output | N/A |
| DirectX* Support | N/A |
| OpenGL* Support | N/A |
| Intel Quick Sync Video | No |
| # of Displays Supported | 0 |
| Package Size | 37.5mm x 37.5mm |
| Clear Video HD Technology | No |
| 4K Support | No |
| Max Memory Bandwidth | 37.5 GB/s |
* NOTE: Image may not exactly match the product
Intel Xeon Server Processor E3-1240 v6 (8M Cache, 3.70 GHz)
The Intel Xeon E3-1240 v6 is a powerful 4-core, 8-thread server processor built on 14nm technology, delivering exceptional performance at 3.70 GHz base frequency with Turbo Boost up to 4.10 GHz. Featuring 8MB Smart Cache and support for DDR4-2400 memory, this processor excels in small business servers, workstations, and entry-level enterprise applications. Key advantages include Intel’s advanced security features, ECC memory support for data integrity, enhanced virtualization capabilities, and improved energy efficiency compared to previous generations. With its optimal balance of performance, reliability, and cost-effectiveness, the E3-1240 v6 is ideal for businesses requiring dependable computing power for databases, web hosting, and multi-tasking server environments without the premium cost of higher-tier Xeon processors.
