Intel Xeon E5-2643 v4 Broadwell 3.4 GHz 6 x 256KB L2 Cache 20MB L3 Cache LGA 2011-3 135W CM8066002041500 Server Processor

The Intel Xeon E5-2643 v4 is a high-performance server processor built on the advanced Broadwell architecture, delivering exceptional computing power with its 3.4 GHz base clock speed and 6 cores. This enterprise-grade CPU features a robust cache hierarchy with 6 x 256KB L2 cache and a substantial 20MB L3 cache, ensuring rapid data access and improved processing efficiency for demanding server workloads. Designed for the LGA 2011-3 socket with a 135W TDP, it strikes an optimal balance between performance and power efficiency. The processor excels in virtualization, database management, and compute-intensive applications, making it ideal for data centers, enterprise servers, and workstations requiring reliable, scalable performance. Its Broadwell architecture provides enhanced security features, improved energy efficiency, and superior multi-threaded performance compared to previous generations, delivering exceptional value for mission-critical server environments.

Quote1 Piece(MOQ) Minimum Order Quantity

Bulk Order Discounts Available

BrandIntel
Products StatusNew
ApplicationServer
CPU Socket TypeFCLGA2011
Total Threads12
Brand

Intel

Products Status

New

Application

Server

CPU Socket Type

FCLGA2011

Total Threads

12

Total Cores

6

Cache

20 MB

TDP

135 W

Manufacturing Tech

14 nm

Processor Base Frequency

3.40 GHz

Memory Types

DDR4 1600/1866/2133/2400

Series

Intel Xeon E5 v4

Part Number

E5-2643V4

Model

CM8066002041500

Hyper-Threading Support

Yes

Max Memory Size

1.5 TB

Code Name

Broadwell

Max Turbo Frequency

3.70 GHz

64-Bit Support

Yes

Max # of Memory Channels

4

Max # of PCI Express Lanes

40

PCI Express Revision

3

Package Size

45mm x 52.5mm

Embedded Options Available

No

Scalability

2S

ECC Memory Supported

Yes

Max CPU Configuration

2

Instruction Set

64-bit

PCI Express Configurations

x16, x4, x8

Max Memory Bandwidth

76.8 GB/s

Bus Speed

9.6 GT/s

Physical Address Extensions

46-bit
