Key Features :
- Device Type : Switch 24 Ports Managed
- Enclosure Type : Rack-mountable 1u
- Subtype : Gigabit Ethernet
- Ports : 24 X 10/100/1000
- Performance : Routing/switching Capacity: 160 Gbps Switching Fabric Bandwidth: 169 Gbps Latency (1 Gbps): 2.8 Latency (10 Gbps): 1.8 Throughput (64-byte Packet Size): 95.2 Mpps
- Capacity : Routing Tables: 10000
- Mac Address Table Size : 64k Entries
- Routing Protocol : Ospf, Bgp-4, Rip-1, Rip-2, Bgp, Ospfv2, Ospfv3
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Snmp 3, Snmp 2c, Ssh-2, Xrmon
- Encryption Algorithm : Ssl
- Authentication Method : Radius, Tacacs+
- Features : Flow Control, Full Duplex Capability, Dhcp Support, Bootp Support, Vlan Support, Syslog Support, Diffserv Support, Sflow, Multiple Spanning Tree Protocol (mstp) Support, Quality Of Service (qos), Jumbo Frames Support, Lldp Support, Link Aggregation Control Protocol (lacp)
- Compliant Standards : Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1s, Ieee 802.1ad, Ieee 802.1v, Ieee 802.1ax
Expansion / Connectivity :
Interfaces : - 24 X 1000base-t – Rj-45
- 1 X Network Stack Device
- 1 X Console – Rj-45
- 1 X Management (lan) – Rj-45
- 1 X Micro-usb
Expansion Slots : - 1 (total) / 1 (free) X Expansion Slot
Power :
- Power Device : Internal Power Supply – Hot-plug
- Installed Qty : 1 (installed) / 2 (max)
- Power Redundancy : Yes
- Power Redundancy Scheme : 1+1 (with Optional Power Supply)
- Power Provided : 250 Watt
- Voltage Required : Dc 12 V
