J9775A Overview
Aruba 2530 Series Gigabit Ethernet devices are enterprise class, fully managed, Layer 2 edge switches delivering cost effective, reliable, and secure connectivity for business networks. Designed for entry level to midsize enterprise networks, these Gigabit Ethernet switches deliver full Layer 2 capabilities with enhanced access security, traffic prioritization, IPv6 host support, and optional PoE+. The 2530 48G model has 48 x 10/100/1000 ports and four Gigabit SFP ports.
Quick Spec
Figure 1 shows the appearance of Aruba J9775A.
Table 1 shows the quick spec.
| Product Code | J9775A |
| Type | Aruba 2530-48G Switch |
| Ports |
|
| Throughput | Up to 77.3 Mp/s (64-byte packets) |
| Switching capacity | 104 Gb/s |
| Dimensions (W x D x H) | 44.3 x 25.4 x 4.45 cm (17.44 x 10.00 x 1.75 in) (1U height) |
| Weight | 3.08 kg (6.8 lb) |
Product Details
Figure 2 shows the front panel of Aruba J9775A.
Note:
| ?? | Power, Fault, and Locator LEDs |
| ?? | Console Port |
| ?? | LED Mode select button and indicator LEDs |
| ?? | 48 ?? RJ-45 autosensing 10/100/1000 ports |
| ?? | 4 ?? SFP slots |
Figure 3 shows the back panel of Aruba J9775A.
Note:
| ?? | AC Power Connector |
