| Brand | xfusion |
|---|---|
| Form Factor | 4U |
| Operating Temperature | 5C to 35C (41F to 95F) (compliant with ASHRAE Class A1/A2/A3) |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Network | Multiple network expansion capabilities, 2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0 |
| Fan Module | 8 x hot-swappable counter-rotating fan modules in N+1 redundancy |
| RAID | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| GPU Card | 4 x dual-width or 10 x single-width GPU cards |
| PSU | 4 x hot-swappable PSUs in N+N/N+M redundancy 1500 W AC Platinum PSUs, 1000 W (input: 100 V to 127 V AC), 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC), 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) 1200 W C48 V to C60 V DC PSUs (input: C38.4 V to C72 V DC) 3000 W AC Titanium PSUs, 2500 W (input: 200 V to 220 V AC), 2900 W (input: 220 V to 230 V AC), 3000 W (input: 230 to 240 V AC), 2000 W AC Platinum PSUs 1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC), 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC) |
| PCIe Expansion | Up to 10 x standard PCIe slots; supporting PCIe 5.0 |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection |
| Management | The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management Can be configured with the FusionDirector management software to provide advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management through the lifecycle |
| Processor | 1 or 2 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor |
| Memory | 32 x DDR5 DIMMs, with up to 4800 MT/s speed |
| Certifications | CE, UL, CCC, FCC, VCCI, and RoHS |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Dimensions (H x W x D) | 175 mm x 447 mm x 798 mm (6.89 in. x 17.60 in. x 31.42 in.) |
| Local Storage | Hot-swappable drives in the following configurations: Up to 32 x 3.5 SAS/SATA drives Up to 4 x NVMe SSDs E1.S SSDs* Flash storage: 2 x M.2 SSDs |
| Chipset | Emmitsburg PCH |
* NOTE: Image may not exactly match the product
FusionServer G5200 V7
The FusionServer G5200 V7 is a high-performance 2U rack server engineered for demanding enterprise workloads and data center environments. This versatile server delivers exceptional computing power through dual Intel Xeon Scalable processors, supporting up to 56 cores and 4TB of DDR4 memory for intensive applications like virtualization, databases, and high-performance computing.
Key features include flexible storage options with up to 24 drive bays supporting NVMe, SAS, and SATA configurations, enabling rapid data access and scalable capacity. The server incorporates advanced thermal management and energy-efficient design, reducing operational costs while maintaining optimal performance. Built-in redundancy features ensure maximum uptime with hot-swappable components and multiple power supply options.
The G5200 V7 stands out with its intelligent management capabilities, featuring comprehensive remote monitoring, automated diagnostics, and simplified deployment tools that reduce administrative overhead. Its modular architecture allows for easy customization and future upgrades, while robust security features protect against evolving threats.
Ideal for enterprises seeking reliable, scalable infrastructure, the FusionServer G5200 V7 combines cutting-edge performance, operational efficiency, and enterprise-grade reliability in a space-optimized form factor, making it perfect for modern data centers requiring maximum performance per rack unit.
Quote1 Piece(MOQ)
Bulk Order Discounts Available
| Brand | xfusion |
|---|---|
| Form Factor | 4U |
| Operating Temperature | 5C to 35C (41F to 95F) (compliant with ASHRAE Class A1/A2/A3) |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Network | Multiple network expansion capabilities, 2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0 |
Inquiry Now
Contact us for more discounts!
