| Brand | xfusion |
|---|---|
| Form Factor | 4U |
| Other Features | |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Network | Expansion capability for multiple types of networks, OCP 3.0 NICs are supported. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported |
| RAID | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| GPU Card | 10 x single-width GPU cards |
| PCIe Expansion | Up to 10 x PCIe slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 10 x PCIe expansion slots. PCIe 5.0 is supported |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection |
| Management | The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management throughout the lifecycle. |
| Processors | 1 or 2 x 4th Gen Intel Xeon Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor |
| Certification | CE, UL, CCC, FCC, VCCI, and RoHS |
| Memory | 32 x DDR5 DIMMs, at 4800 MT/s |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Fan Modules | 6 or 8 x hot-swappable counter-rotating fans in N+1 redundancy |
| Power Supply | 2 x hot-swappable PSUs in 1+1 redundancy mode. Supported options include: 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC). 1500 W AC Platinum PSUs, 1000 W (input: 100 V to 127 V AC), 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC), 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC), 1200 W C48 V to C60 V DC PSUs (input: C38.4 V to C72 V DC). 3000 W AC Titanium PSUs, 2500 W (input: 200 V to 220 V AC), 2900 W (input: 220 V to 230 V AC), 3000 W (input: 230 to 240 V AC). 2000 W AC Platinum PSUs, 1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC), 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC) |
| Dimensions (H x W x D) | Chassis with 3.5 drives: 175 mm 447 mm 798 mm (6.89 in. x 17.60 in. x 31.42 in.) |
| Local Storage | Hot-swappable drive configurations: 4 x 2.5 SAS/SATA drives/SSDs 24 to 44 x 3.5 SAS/SATA drives 8 x NVMe SSDs E1.S or E3.S SSDs* Flash storage: 2 x M.2 SSDs |
| Chipset | Emmitsburg PCH |
* NOTE: Image may not exactly match the product
FusionServer 5288 V7 Rack Server
Quote1 Piece(MOQ)
| Brand | xfusion |
|---|---|
| Form Factor | 4U |
| Other Features | |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Network | Expansion capability for multiple types of networks, OCP 3.0 NICs are supported. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported |
