CloudDC A+ Server AS -1115CS-TNR (Complete System Only wholesale

* NOTE: Image may not exactly match the product

CloudDC A+ Server AS -1115CS-TNR (Complete System Only

**CloudDC A Server AS-1115CS-TNR Complete System**

High-performance 1U rackmount server engineered for enterprise data centers and cloud infrastructure. Features dual Intel Xeon Scalable processors with up to 40 cores, supporting massive parallel workloads and virtualization environments. Equipped with 16 DIMM slots accommodating up to 4TB DDR4 memory for memory-intensive applications.

**Key Features:**
– Compact 1U form factor maximizing rack density
– Redundant hot-swappable power supplies ensuring 99.9% uptime
– Advanced thermal management with optimized airflow design
– Multiple PCIe 4.0 slots for high-speed storage and network expansion
– Integrated IPMI 2.0 for remote management and monitoring
– Tool-less chassis design for rapid deployment and maintenance

**Benefits:**
– Reduces total cost of ownership through energy-efficient architecture
– Scales seamlessly from small business to enterprise deployments
– Minimizes downtime with redundant components and hot-swap capabilities
– Accelerates data processing with latest-generation processors and memory

**Unique Selling Points:**
– Complete turnkey solution requiring no additional components
– Enterprise-grade reliability with 5-year warranty coverage
– Optimized for virtualization, databases, and high-performance computing
– Industry-leading performance-per-watt ratio in compact footprint

Quote1 Piece(MOQ)

Premium Client Discounts Available

BrandSupermicro
Products StatusNew
ApplicationsCDN, Cloud Computing, Compact Server, Data Center Optimized, DNS & Gateway Servers, Edge Nodes, Firewall Application, Value IaaS, Web Server
Max GPU1
CPU TypeAMD EPYC 9004/9005 Series Processors

Product SKUs

  • A+ ServerAS -1115CS-TNRStandard version with PWS-860P-1R2 (Platinum Level)
  • A+ ServerAS -1115CS-TNR-EUEuropean version with PWS-861A-1R (Titanium Level)
  • A+ ServerAS -1115CS-TNR-G1Gold Series version with pre-configured components

Motherboard

  • Super H13SSW

Processor

  • CPU
    Single processor(s)
    AMD EPYC 9004/9005 Series Processors (* AMD EPYC 9005 Series drop-in support requires board revision 2.x)
  • Core Count
    Up to 160C/320T

GPU

  • Max GPU Count
    Up to 2 single-width GPUs
  • Supported GPU
    NVIDIA PCIe: L4, A2
  • CPU-GPU Interconnect
    PCIe 5.0 x16 CPU-to-GPU Interconnect
  • GPU-GPU Interconnect
    PCIe

System Memory

  • Memory
    Slot Count: 12 DIMM slots
    Max Memory (1DPC): Up to 3TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC 9004 Series Processor)
    Max Memory (1DPC): Up to 4.5TB 6000MT/s ECC DDR5 RDIMM (AMD EPYC 9005 Series Processor)
  • Memory Voltage
    1.1V

On-Board Devices

  • Chipset
    System on Chip
  • Network Connectivity
    Via AIOM

Input / Output

  • LAN
    1 RJ45 1 GbE Dedicated BMC LAN port
  • USB
    2 USB 3.0 ports(rear)
    2 USB 2.0 ports(front)
  • Video
    1 VGA port
  • Serial
    1 COM port(Rear)
  • TPM
    1 TPM header

System BIOS

  • BIOS Type
    AMI 32MB SPI Flash ROM
  • BIOS Features
    ACPI 6.4
    Plug and Play (PnP)
    SMBIOS 3.5 or later
    UEFI 2.8
    USB Keyboard support

Management

  • Power configurations
    ACPI Power Management
    Power-on mode control for AC power loss recovery
    Power button override mechanism,

Chassis

  • Form Factor
    1U Rackmount
  • Model
    CSE-LB16TS-R860AWP-A

Dimensions and Weight

  • Height
    1.7″ (43 mm)
  • Width
    17.2″ (437 mm)
  • Depth
    23.5″ (597 mm)
  • Package
    7.8″ (H) x 23.8″ (W) x 32.4″ (D)
  • Weight
    Gross Weight: 46 lbs (20.9 kg)
    Net Weight: 25 lbs (11.3 kg)
  • Available Color
    Black front & sliver body

Front Panel

  • LED
    Drive activity
    Network activity
    Power status
    Universal Information (UID)
  • Buttons
    Power On/Off
    Universal Information (UID)

Expansion Slots

  • PCI-Express (PCIe) Configuration
    Default 2 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

Drive Bays / Storage

  • Drive Bays Configuration
    Default: Total 10 bays 10 front hot-swap 2.5″ SATA drive bays
    Option A: Total 10 bays 10 front hot-swap 2.5″ PCIe 5.0 NVMe* drive bays
    Option B: Total 10 bays 10 front hot-swap 2.5″ SAS* drive bays
    (*NVMe/SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
  • M.2
    2 M.2 PCIe 3.0 x2 NVMe slots (M-key 2280/22110)

System Cooling

  • Fans
    6x 4cm heavy duty fans with optimal fan speed control
  • Air Shroud
    1 Air Shroud

Power Supply

  • 2x 860W
    2x 860W
    2x 860W
    2x 860W Redundant Platinum Level (94%) power supplies
    Dimension (WxHxL)
    54.5 x 40.25 x 322 mm
    Input
    800W: 100-127Vac
    800W: 100-127Vac / 50-60Hz
    860W: 200-240Vac
    860W: 200-240Vdc / 50-60Hz
    860W: 200-240Vac / 50-60Hz
    +12V
    Max: 66.6A / Min: 0A (100Vac-127Vac)
    Max: 71.6A / Min: 0A (200Vdc-240Vdc)
    Max: 71.6A / Min: 0A (200Vac-240Vac)
    5V SB
    Max: 4A / Min: 0A
    Output Type
    Backplanes (gold finger)
    2x 860W
    2x 860W Redundant Titanium Level (96%) power supplies
    Dimension (WxHxL)
    54.5 x 40.25 x 322 mm
    Input
    800W: 100-127Vac / 50-60Hz
    860W: 200-240Vac / 50-60Hz
    860W: 240Vdc / 50-60Hz
    +12V
    Max: 66.67A / Min: 0A (100Vac-127Vac)
    Max: 71.67A / Min: 0A (200Vac-240Vac)
    Max: 71.67A / Min: 0A (Vdc-240Vdc)
    5V SB
    Max: 4A / Min: 0A
    Output Type
    Backplanes (gold finger)
Brand

Supermicro
Products Status

New
Applications

CDN, Cloud Computing, Compact Server, Data Center Optimized, DNS & Gateway Servers, Edge Nodes, Firewall Application, Value IaaS, Web Server
Max GPU

1
CPU Type

AMD EPYC 9004/9005 Series Processors
Total PCI-E Slots

2
Drives

10
Drive Form Factors

2.5"
Form Factor

1U
Generation

H13
Interface

NVMe (Optional), SAS (Optional), SATA (Native)
LED

Drive activityNetwork activityPower statusUniversal Information (UID)
Max GPU Count

Up to 2 single-width GPUs
Serial

1 COM port(Rear)
CPU-GPU Interconnect

PCIe 5.0 x16 CPU-to-GPU Interconnect
Supported GPU

A2View GPU Options, NVIDIA PCIe: L4
Air Shroud

1 Air Shroud
Network Connectivity

Via AIOMView AIOM OptionsView AOC Options
BIOS Features

ACPI 6.4Plug and Play (PnP)SMBIOS 3.5 or laterUEFI 2.8USB Keyboard support
LAN

1 RJ45 1 GbE Dedicated BMC LAN port
BIOS Type

AMI 32MB SPI FLASH ROM
Package

7.8" (H) x 23.8" (W) x 32.4" (D)
Depth

23.5" (597 mm)
Fans

6x 4cm heavy duty fans with optimal fan speed control
Height

1.7" (43 mm)
Buttons

Power On/OffUniversal Information (UID)
M.2

2 M.2 PCIe 3.0 x2 NVMe slots (M-key 2280/22110)
GPU-GPU Interconnect

PCIe
Width

17.2" (437 mm)
Video

1 VGA port
Core Count

Up to 160C/320T
Weight

Gross Weight: 46 lbs (20.9 kg)Net Weight: 25 lbs (11.3 kg)
Drive Bays Configuration

Default: Total 10 baysOption A: Total 10 baysOption B: Total 10 bays(*NVMe/SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
USB

2 USB 3.0 ports(rear)2 USB 2.0 ports(front)
Available Color

Black front & sliver body
PCI-Express (PCIe) Configuration

Default
TPM

1 TPM Header
CPU

Single processor(s)AMD EPYC 9004/9005 Series Processors
Chipset

System on Chip
Memory Voltage

1.1V
