* NOTE: Image may not exactly match the product

Brocade ICX7450-48F 48-Ports Layer-3 Rack-Mountable Managed Switch

The Brocade ICX7450-48F is a high-performance 48-port Layer-3 managed switch designed for enterprise networks requiring robust switching capabilities and advanced routing features. This rack-mountable solution delivers wire-speed performance across all ports with comprehensive Layer-3 functionality including OSPF, BGP, and VRRP protocols. Key features include stackable architecture supporting up to 12 units for 576 ports, redundant power supply options for maximum uptime, and advanced security with 802.1X authentication and ACLs. The switch offers flexible deployment with both fiber and copper connectivity options, energy-efficient operation, and centralized management through Brocade’s Network Advisor. Its unique selling points include exceptional port density, enterprise-grade reliability with lifetime warranty, seamless integration with existing Brocade infrastructure, and cost-effective scalability for growing networks. Ideal for data centers, campus cores, and distribution layers where high availability and performance are critical.

Quote1 Piece(MOQ)

Bulk Order Discounts Available

BrandBrocade
Width17.3 in
Depth15.5 in
Height1.7 in
Weight14.99 lbs
Brand

Brocade

Width

17.3 in

Depth

15.5 in

Height

1.7 in

Weight

14.99 lbs

Min Operating Temperature

23 ??F

Max Operating Temperature

122 ??F

Humidity Range Operating

5 – 95% (non-condensing)

Min Storage Temperature

-13 ??F

Max Storage Temperature

158 ??F

Humidity Range Storage

0 – 95% (non-condensing)

Device Type

Switch – 48 ports – L3 – managed – stackable

Enclosure Type

Rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

48 x Gigabit SFP

Performance

Switching capacity: 336 Gbps, Forwarding performance: 250 Mpps, Stacking bandwidth: 160 Gbps

Capacity

Virtual interfaces (VLANs): 4096, Spanning Tree Protocol instances: 254, IPv4 routes: 16000, IPv6 routes: 3000

MAC

Address Table Size 32000 entries

Jumbo Frame Support

9216 bytes

Max Units In A Stack

12

Routing Protocol

IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, ECMP, MLDv2, MLD

Remote Management Protocol

SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, CLI

Encryption Algorithm

AES
